1.0 Introduction
Thank you for your purchase of the intimus
With proper maintenance your unit will provide you with years of service. Upon receiving the machine verify that
there are no signs of shipping damage on the exterior. If you feel the product may have been damaged in tran-
sit, contact the appropriate freight carrier immediately, then contact technical support at Martin Yale Industries,
Inc. at 260-563-0641.
Upon opening the machine, verify that you have the following components.
2.0 Contents
- Card Slitter Unit
- Cabinet
- Cabinet Top
- Operating Instructions
- Waste Receptacle
- Poly bag (waste)
Operating Instructions
GC208
line of Business Card Slitters or Scoring/Perforating machines.
®
Model:
Serial No:
Manuf. Date:
Advertisement
Table of Contents
Related Manuals for Intimus GC208
Summary of Contents for Intimus GC208
- Page 1 Operating Instructions GC208 1.0 Introduction Thank you for your purchase of the intimus line of Business Card Slitters or Scoring/Perforating machines. ® With proper maintenance your unit will provide you with years of service. Upon receiving the machine verify that there are no signs of shipping damage on the exterior.
- Page 2 > Max. Sheet Size 8 ½" X 11" > Speed: 300 finished cards per minute. > Dimensions: 17” x 11 3/4” x 39” > Weight: GC208 unit - 39 lbs. Cabinet - 31 lbs. 4.0 Set up from the carton to the table Caution: The unit contains rotating blades and other dangerous items.
- Page 3 5. Insert the paper support tabs into the bottom feed shelf slots as shown (Fig. 6). Fig. 6 Attach the paper support 5.0 Operation Caution: The unit contains rotating blades and other dangerous items. Do not remove any safety covers from the machine. Be aware that loose jewelry, long hair and loose fitting clothes should be kept away from the unit.
- Page 4 5. Remove the two stacks of strips and place together while keeping them oriented in the same direction (Fig. 10). Neatly square up the edges of the stack for prepara- tion to insert into the upper feed shelf for the final cut. Fig.
- Page 5 10. Whenever possible, place a book or other weighted material on top of your freshly printed stock to prevent excessive curling of the material. If the material is curled and does not want to feed well, this unit comes with two top plates to be placed on top of the cardstock when positioned for feeding, but may also have inconsistent feeding (Fig.
- Page 7 8-UP FORMAT GUTTER CUT...
- Page 8 251 Wedcor Avenue Wabash, Indiana 46992 Phone (260) 563-0641 Fax (260) 563-4575 Email: info@martinyale.com Website: www.martinyale.com M-S027121 12/7/06...
