Description
Connector, unshielded, female, angled, M
12 A–coded, 4–position. This connector is
manufactured by Phoenix Contact.
*Used with permission of Phoenix Contact GmbH & Co. KG.
Important Notice
Warning!
Electrical shock could cause death or serious injury. If the sensor is
installed in a high voltage environment and a fault or installation error
occurs, high voltage may be present on the TSM 470A–VN or the probe
itself.
Safe and secure operation of the compact RTD transmitter can only be guaranteed if the
operating instructions (BA 162R/24/ae) and all safety notes are read, understood and followed.
Visit www.us.endress.com/temp.
Correct use
The manufacturer cannot be held responsible for damage caused by misuse of the unit.
The installation conditions and connection values indicated in the operating instructions must
be followed!
Installation, commissioning and operation
The unit is constructed using the most up to date production equipment and complies to the
safety requirements of the local guidelines. However, if it is installed incorrectly or misused,
certain application dangers can occur. Installation, wiring and maintenance of the unit must
only be done by trained skilled personnel who are authorized to do so by the plant operator.
This skilled staff must have read and understood these instructions and must follow them to
the letter. The plant operator must make sure that the measurement system has been correctly
wired to the connection schematics.
Hazardous areas
Installation of the compact RTD transmitter in hazardous areas is prohibited!
Returns
Please follow the Return Authorization Policy in the operating instructions (BA 162R/24/ae).
All Temperature Operating Instructions are available on CD–ROM, Part Number SONDTT–AG.
Safety pictograms and symbols
Note!
Notes draw attention to activities or procedures that can have a direct influence on
operation or trigger an unforeseen device reaction if they are not carried out properly.
Caution!
Cautions draw attention to activities or procedures that can lead to persons being
injured or to incorrect device operation if they are not carried out properly.
Warning!
Warnings draw attention to activities or procedures that can lead to persons being
seriously injured, to safety risks or to the destruction of the device if they are not
carried out properly.
Though the information provided herein is believed to be accurate, be advised that the information contained
herein is NOT a guarantee of satisfactory results. Specifically, this information is neither a warranty nor guarantee,
expressed or implied, regarding performance; merchantability, fitness, or other matter with respect to the
products; and recommendation for the use of the product/process information in conflict with any patent. Please
note that Endress+Hauser reserves the right to change and/or improve the product design and specifications
without notice.
easytemp™ TSM 470A–VN
Connector
Short Operating Instructions
*
+
