ACO PRO I/O Installation Manual

INSTALLATION MANUAL FOR PRO I/O, PRO I/O–60
GENERAL INFORMATION
PRO-I/O and PRO-I/O-60 modules are optional extension
modules for PRO system with relay output and switch
output. Both modules have equal function, difference
between them is only visual.
PRO-I/O module has standard ACO housing, possible to
suface mount (dimensions: 71x70,5x19,4 mm) and it has
Rj45 socket and screw terminals for connecting the wires.
PRO-I/O-60 is equipped only with screw terminals for
wires connection, the size (cross-sections is 50 mm)
allows putting the module into 60 mm electric back boxes.
PRO-I/O module optionally extends the system with relay
output and normally open (NO) input. The latter can be
used to call certain receivers (from additional door bell
button) or from remote opening activation (typical
activation of e-lock).
NC/NO contact points work either in monostable or
bistable mode and they can be used to control additional
gate, lights or external calling signal can be connected to
it.
TECHNICAL PARAMETERS
Power voltage
•
Max. power consumption
•
Power consumption in standby
•
Contacts load
•
Type of external trigger
•
Resistance
•
Contacts type
•
Sockets type
•
Work mode
•
Additional calling type
•
62-002 Suchy Las, ul. Diamentowa 7, tel./ fax + 48 61 843 93 71
In case call incoming from the I/O module the receiver
shows the picture from the camera (if available) and starts
to ring. Calling from the I/O module is shown by pulsating
key icon and lasts for 10 s. and the receivers with handset
ring with different tone. In order to enable the relay in the
I/O module use F2 button (circle icon). Any action at the
receiver during incoming call from the module cancels the
call and enables the desired action. When the call signal
mode is enabled, the I/O module enables the relay while
there is call from the panel and when the module's input
gets the contact, the I/O module will automatically open
the door. When the input has a permanent contact, every
call from the panel will enable the relay for 1 s and will
open the door.The module can work also as a relay and
trigger the e-lock for the time set in the outside unit, it
doesn't concern opening from the INPUT function of the
outside station (this feature is available in the software
version of the module 2.1 and the panel's version from
v.1.1.5)
15VDC ±5%
35mA
~0,14W
5A/250VAC
NO switch
≤ 20Ω
NO/NC with common point COM
RJ45 socket / screw terminals ARK
monostable / bistable
Normally open (NO)
