Klutch 49675 Owner's Manual

30in. w capacity 3-in-1 combination sheet metal machine
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
30in. W Capacity 3-in-1
Combination Sheet Metal Machine
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and
other basic safety precautions may result in serious personal injury.
Item# 49675
Thank you very much for choosing a Klutch product. For future reference, please complete the
owner's record below:
Serial Number/Lot Date Code: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This 30-inch wide capacity 3-in-1 combination sheet metal is designed for certain applications
only. The distributor cannot be responsible for issues arising from modification or use of this
product in an application for which it was not designed. We strongly recommend that this
product not be modified and/or used for any application other than that for which it was
designed.
For technical questions please call 1-800-222-5381.

Table of Contents

Intended Use ----------------------------------------------------------------------------------------------- 1
Technical Specifications ---------------------------------------------------------------------------------- 1
Important Safety Information ----------------------------------------------------------------------------- 2
Specific Operation Warnings ----------------------------------------------------------------------------- 3
Assembly --------------------------------------------------------------------------------------------------- 3
Before Each Use ------------------------------------------------------------------------------------------- 4
Operating Instructions ------------------------------------------------------------------------------------ 4
After Each Use --------------------------------------------------------------------------------------------- 6
Maintenance ----------------------------------------------------------------------------------------------- 6
Parts Diagram ---------------------------------------------------------------------------------------------- 7
Parts List --------------------------------------------------------------------------------------------------- 8
Troubleshooting ------------------------------------------------------------------------------------------- 9
Replacement Parts ---------------------------------------------------------------------------------------- 9
Limited Warranty ------------------------------------------------------------------------------------------- 9
Intended Use
This 30 inch 3-In-1 combination sheet metal machine is a versatile combination unit that allows
cutting, bending and shaping mild steel sheet metal as well as other metals. It is designed for
precision shearing, braking, and rolling tubes, cones or rings according to the specifications below.
Technical Specifications
Property
PRESS BRAKE
Bending length
Max. Bend capacity in mild steel
SLIP ROLL
Slip roll capacity in mild steel
Diameter rolls
Wire grooves
SHEAR
Max. Shear capacity
Max. Cutting length
SIZE OF DIE SETS
30"
SHIPPING WEIGHT
30in. W Capacity 3-in-1 Combination
Sheet Metal Machine
OWNER'S MANUAL
Purchase Date: _______________
Specification
30" (762mm)
0.04" (20 gauge; 1mm)
0.04" (20 gauge; 1mm)
1-1/2" (38mm)
11/64"(4-1/2mm)
0.04" (20 gauge; 1mm)
30" (762mm)
1 Female and
1", 2", 3", 4", 5", 6",10" Male
330 lbs
1 of 10

Advertisement

loading

Related Manuals for Klutch 49675

Summary of Contents for Klutch 49675

  • Page 1: Table Of Contents

    30in. W Capacity 3-in-1 Combination Sheet Metal Machine OWNER’S MANUAL Thank you very much for choosing a Klutch product. For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: _______________ Purchase Date: _______________ 30in. W Capacity 3-in-1 Save the receipt, warranty and these instructions.

  • Page 2: Important Safety Information

    30in. W Capacity 3-in-1 Combination 30in. W Capacity 3-in-1 Combination Sheet Metal Machine Sheet Metal Machine OWNER’S MANUAL OWNER’S MANUAL Important Safety Information CAUTION: WARNING: PRODUCT USE AND CARE • Read and understand all instructions. Failure to follow all instructions may result in serious •...

  • Page 3: Before Each Use

    30in. W Capacity 3-in-1 Combination 30in. W Capacity 3-in-1 Combination Sheet Metal Machine Sheet Metal Machine OWNER’S MANUAL OWNER’S MANUAL Before Each Use • To adjust the lower shear blade (23), loosen the screw (60) at the end of each table. Under- neath the table, there are two adjustment screws (17) on the left and right side.

  • Page 4: After Each Use

    30in. W Capacity 3-in-1 Combination 30in. W Capacity 3-in-1 Combination Sheet Metal Machine Sheet Metal Machine OWNER’S MANUAL OWNER’S MANUAL After Each Use Parts Diagram • When the machine will not be used for a while, remove any debris or scraps of metal, clean it, and spread a thin coat of oil on the unpainted surfaces to prevent rust.

  • Page 5: Parts List

    Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser HANDLE ARM FLAT WASHER 8MM only ("You'' or “Your”) that the Klutch product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from THREADED ROD HEX BOLT M6-1.0 X 45...
  • Page 6 30in. W Capacity 3-in-1 Combination Sheet Metal Machine OWNER’S MANUAL Remedy Limits Product replacement or a refund of the purchase price is Your sole remedy under this limited warranty or any other warranty related to the product. We shall not be liable for: service or labor charges or damage to Your property incurred in removing or replacing the product;...
