52in. W Capacity 3-in-1 Combination
Sheet Metal Machine
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and
other basic safety precautions may result in serious personal injury.
Item# 49679
Thank you very much for choosing a Klutch product. For future reference, please complete the
owner's record below:
Serial Number/Lot Date Code: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This52-inch wide capacity 3-in-1 combination sheet metal machine is designed for certain
applications only. The distributor cannot be responsible for issues arising from modification or
use of this product in an application for which it was not designed. We strongly recommend
that this product not be modified and/or used for any application other than that for which it
was designed.
For technical questions please call 1-800-222-5381.
Table of Contents
Intended Use ----------------------------------------------------------------------------------------------- 1
Technical Specifications ---------------------------------------------------------------------------------- 1
Important Safety Information ----------------------------------------------------------------------------- 2
Specific Operation Warnings ----------------------------------------------------------------------------- 3
Assembly --------------------------------------------------------------------------------------------------- 3
Before Each Use ------------------------------------------------------------------------------------------- 4
Operating Instructions ------------------------------------------------------------------------------------ 4
After Each Use --------------------------------------------------------------------------------------------- 5
Maintenance ----------------------------------------------------------------------------------------------- 5
Parts Diagram ---------------------------------------------------------------------------------------------- 6
Parts List --------------------------------------------------------------------------------------------------- 7
Troubleshooting ------------------------------------------------------------------------------------------- 8
Replacement Parts ---------------------------------------------------------------------------------------- 8
Limited Warranty ------------------------------------------------------------------------------------------- 8
Intended Use
This 52-inch wide capacity 3-in-1 combination sheet metal machineis a versatile combination unit
that allows cutting, bending and shaping mild steel sheet metal as well as other metals. It is
designed for precision shearing, braking, and rolling tubes, cones or rings according to the
specifications below.
Technical Specifications
Property
Effective width
Maximum shearingthickness
Maximum braking thickness
Maximum rolling thickness
Minimum internal diameterof the roll
Dies
Dimensions (L×W×H)
Net weight of machine tool
52in. W Capacity 3-in-1 Combination
Sheet Metal Machine OWNER'S MANUAL
Purchase Date: _______________
Specification
52 inches (1320mm)
20 gauge (1mm) low carbon plate
20 gauge (1mm) low carbon plate
20 gauge (1mm) low carbon plate
1.97 inches (50mm)
1 female, 9 male
65.7" x 25.6" x 18.9" (1670 x 650 x 480mm)
617 lbs. (280kg)
1 of 9
Advertisement
Table of Contents
Related Manuals for Klutch 49679
Summary of Contents for Klutch 49679
- Page 1 52in. W Capacity 3-in-1 Combination Sheet Metal Machine OWNER’S MANUAL Thank you very much for choosing a Klutch product. For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: _______________ Purchase Date: _______________ 52in. W Capacity 3-in-1 Combination Save the receipt, warranty and these instructions.
- Page 2 52in. W Capacity 3-in-1 Combination 52in. W Capacity 3-in-1 Combination Sheet Metal Machine OWNER’S MANUAL Sheet Metal Machine OWNER’S MANUAL Important Safety Information CAUTION WARNING: PRODUCT USE AND CARE • DO NOT allow persons to operate or assemble this product until they have read this manual •...
- Page 3 52in. W Capacity 3-in-1 Combination 52in. W Capacity 3-in-1 Combination Sheet Metal Machine OWNER’S MANUAL Sheet Metal Machine OWNER’S MANUAL Adjustment of the positioning plate: Before Each Use: During the period of the shearing, there will be a powerful strengthen produced at the middleof Check for damaged parts before each use.
- Page 4 52in. W Capacity 3-in-1 Combination 52in. W Capacity 3-in-1 Combination Sheet Metal Machine OWNER’S MANUAL Sheet Metal Machine OWNER’S MANUAL Parts Diagram Parts List Part No. Description Q’ty Part No. Description Q’ty Left wall Upper pressing roll Work bench Protecting cover Crossbeam Rotation shaft Crank arm...
- Page 5 Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Klutch product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase.
- Page 6 52in. W Capacity 3-in-1 Combination Sheet Metal Machine OWNER’S MANUAL Distributed by Northern Tool and Equipment Company, Inc. Burnsville, Minnesota 55306 NorthernTool.com Made in China...
