INSTALLATION
· assembling the top part of the speaker
Before assembling the top part it is good idea to find a
preliminary location for the speaker in the room and install the
bottom part of the speaker there.
While holding the top part, connect the cable connector of top
part to the XLR-connector of the bottom part. The XLR-connector
is situated inside the bottom part and is accessed through the
opening in the top plate of the bottom part. You will hear a
"click-sound" when the cable connector is locked properly.
Make sure that the cable between the top and bottom fits well
inside the bottom part. The top part should rest firmly on the
three silicone plugs. When repositioning the speaker, it is
always recommended to remove the top part of the speaker to
avoid damages.
The top part can be turned both horizontally and vertically. The
unique feature allows fine-tuning for the sonic image and room
reflections.
5
