- Page 1 ThermoVault Max Extreme Temperature Thermal Barrier Product User Guide 1.800.561.8187 information@itm.com www. .com...
-
Page 2: Product Overview
Product User Guide Product Overview Compatible Data Loggers » HiTemp140-M12 The ThermoVault Max is an extreme, high temperature thermal barrier designed for use with the HiTemp140 series. This » HiTemp140-FP durable thermal barrier can withstand temperatures up to » HiTemp140-PT +400 °C in dry heat applications and +250 °C in wet applications... - Page 3 O-Ring maintenance is a key factor when properly caring for the ThermoVault Max. Please refer to the application note “O-Rings 101: Protecting Your Data Logger,” found on the MadgeTech website, for information on how to prevent O-Ring failure.
- Page 4 Product User Guide 3. Holding the smooth metal end of the stopper, 4. Insert the Compression Ferrule into the use a 7/16” wrench or socket to tighten the body Fitting Body and hold it in place loosely with the into the stopper. Dome Nut.
-
Page 5: General Specifications
Barrier Weight 3.0 lb (1350 g) Max Sustainable Pressure 60 PSIA *When using the ThermoVault Max with the HiTemp140-M12 data logger, only certain M12 probes are compatible. Please consult with the a MadgeTech Sales Representative for more information. 1.800.561.8187 information@itm.com www. - Page 6 Product User Guide Time vs. Temperature Chart Maximum Exposure Time Maximum Exposure Time Ambient Temperature (air) (liquid) -200 °C 128 minutes -180 °C 137 minutes -160 °C 148 minutes -140 °C 163 minutes -120 °C 183 minutes -100 °C 213 minutes -80 °C 263 minutes -60 °C...
- Page 7 ThermoVault Max to continue to heat the data logger to potentially unsafe levels. The ThermoVault Max may take hours to fully cool down. Even if the exterior of the ThermoVault Max is cool to the touch, the interior of the barrier and its contents may still be VERY hot.
-
Page 8: Need Help
» Visit our Knowledge Base online. » Contact our friendly Customer Support Team Software Information & Support: » Refer to the built-in help section of the MadgeTech 4 Software. » Download the MadgeTech 4 Software Manual DOC-1322035-00 REV 1 2016.01.27 1.800.561.8187...
