- Page 1 User Manual LCD1U15-06 / LCD1U17-02 -8KVM / 16KVM 1U LCD Keyboard Drawer with PS/2 KVM Switch...
-
Page 2: Table Of Contents
Table Of Content Table of Content Introduction Features Package Contents Optional Accessories Peripheral Products Important Safeguards Structure Diagram Dimension Diagram LCD1U15-06-8KVM/16KVM LCD1U17-02-8KVM/16KVM 10. LCD Session LCD Membrane Diagram P.10 LCD OSD Control P.10 Main Menu P.11-12 Sub Menu Resolution Settings P.13... -
Page 3: Introduction
User Manual Introduction RKP Series is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide effective assistant for an administrator to control PC system. RKP Series provides cost effective for your limited IT budget over using CRT and rack mounting. -
Page 4: Package Contents
User Manual Package Contents LCD Monitor Drawer with PS/2 KVM Switch 1 Piece User Manual 1 Piece DC Power Adapter 1 Piece Power Cord 1 Piece Mounting Bracket 1 Pair Fasteners 4 Pieces LCD-A1004 3-in-1 KVM cable 8 Pieces Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. -
Page 5: Optional Accessories
User Manual Optional Accessories KVM Cable LCD-A1004 / 05 / 06 6ft / 10ft / 15ft PS/2 3-in-1 cable Cascade Cable LCD-A1018 / 21 / 22 6ft / 10ft / 15ft PS/2 3-to-3 cable Conversion Adapter LCD-A1001 SUN / iMAC USB to PS/2 adapter Others Video Input 12V / 24V / 48V DC Power... -
Page 6: Important Safeguards
User Manual Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a ●... -
Page 7: Structure Diagram
User Manual Structure Diagram PS/2 keyboard Aluminium front panel Class A active matrix TFT LCD panel Rear metal case Analog to digital signal converter board LCD inverter LCD membrane Ball bearing telescopic slides with stopper Adjustable mounting bracket KVM membrane & KVM switch board ‚... -
Page 8: Dimension Diagram
User Manual Dimension Diagram LCD1Y15-06-8KVM / 16KVM 15” LCD Rev. : 1.0... -
Page 9: Lcd1U17-02-8Kvm/16Kvm
User Manual Dimension Diagram LCD1U17-02-8VKM / 16KVM 17” LCD Rev. : 1.0... -
Page 10: Lcd Session
User Manual Session Rev. : 1.0... -
Page 11: Lcd Membrane Diagram
User Manual LCD Session LCD Membrane Diagram Power Menu/Selection Exit Right Left MAIN MENU BRIGHT/CONTRAST AUTO ADJUST PHASE/CLOCK H/V POSITION MISC RESET Main Menu Bright / Contrast To enter into the Bright, Black level & Contrast sub-menu ● Auto Adjust To perform automatic optimisations of all functions ●... - Page 12 User Manual LCD Session Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal ● to “Brightness” Use the Left & Right button to adjust and button ● 2. Contrast To adjust the contrast level of the input signal ●...
- Page 13 User Manual LCD Session MISC 1. Information The first header row shows the current resolution setup ● The second header row shows the horizontal frequency of the current ● input signal The third header row shows the vertical frequency of the current input ●...
-
Page 14: Resolution Settings
User Manual LCD Session Resolution Settings For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 1.0 P.13... -
Page 15: For Sun Servers
User Manual LCD Session Resolution Settings For SUN Servers Resolution configuration procedures should be run by qualified SUN ● server administrator Sun Servers are using resolution at 1152 x 900 x 76Hz. ● Supported resolution mode for 15” LCD: ● 1024 x 768 x 70/75Hz ●... -
Page 16: Kvm Session
User Manual Session Rev. : 1.0 P.15... -
Page 17: Front View
User Manual KVM Session Front View Bank No. Selected Channel Bank Button Online Channel Channel Select Button Shift Button LED Indication Selected Channel - Displayed channel on monitor & red in LED. Channel select button - Press to select channel from 1 – 8. Shift button - Press &... -
Page 18: Rear View
User Manual KVM Session Rear View Channel Cascade Port Power Port 8KVM 16KVM DC Power -connect to external 12V DC power adapter. Cascade Port -connect to additional KVM switch for channel expansion. Channel Port -connect to PC computer with LCD-A1004 3-in-1 KVM cable. Rev. -
Page 19: Installation Steps
User Manual KVM Session Installation Steps Before installation, please make sure all of peripherals and computers have been turned off. Connect the 3-in-1cable with 2 mini-din 6-pin connectors and a HDDB 15-pin connector to the computer ports. Connect another end of the cable to KVM switch. Plug the power adapter included to the LCD Keyboard Drawer. -
Page 20: Cascading
User Manual KVM Session Cascading Using CA-6 PS/2 KVM cable to connect from Bank 1’s “Cascade port” to Bank 2’s “Console port”. After connected please press “Bank” & “Channel” button on the front of the PS/2 KVM switch to reset the PS/2 KVM switch. Bank 1 LCD-A1018 PS/2 KVM cable Bank 2... -
Page 21: Start Up
User Manual Start Up The channels that have PC connected and it is switch on will have a green LED on that channel. The red LED will indicate the selected channel. 7 segments LED will display the bank number. Press channel button to select the channel. Enter the password, default is “00000000”... -
Page 22: Hotkey Command Operation
User Manual Start Up Hot-key Command Operation Calling OSD Menu Scroll Scroll Space Bar Switch to Previous Port (powered on PC only) £ Scroll Scroll Switch to Next Power On Port (powered on PC only) ¤ Scroll Scroll Switch to Previous Bank First digit of Port Number: Scroll Scroll... - Page 23 User Manual Start Up HotKey Command Operation Switch to Next Bank Scroll Scroll PgDn Enable / Disable beeper sound Scroll Scroll Note: The default Beeper function is ON and beeper control is only for Auto Scan for Powered on PC Scroll Scroll Reset to factory Default Setting...
-
Page 24: Osd Structure Diagram
User Manual Start Up OSD Structure Diagram Bank Session BANK : 1 ® SYSTEM 02 BANK : 1 SYSTEM ® SYSTEM 02 E ® SYSTEM 03 ® SYSTEM 04 SYSTEM PC Session ® SYSTEM 03 ® SYSTEM 04 ® SYSTEM 05 SYSTEM 06 ®... - Page 25 User Manual Start Up KVM Settings Session OSD Menu on screen time ● default is 10 seconds. It can be modified from 05 – 99 ● seconds. Scan Scan interval from one PC port ● to next PC port when applying █...
-
Page 26: 13. Faq
User Manual 13. FAQ 1. Don’t press any keys on the keyboard while the selected computer is booting up. Otherwise, it might cause the keyboard error or keyboard is not detected at PC side. 2. The computer boot up fine, but keyboard doesn’t work. Make sure the keyboard works when directly plugged into the computer. -
Page 27: Technical Specification
User Manual Technical Specification Item Specification KVM Channel Port 8 port / 16 port KVM Channel Interface HDDB 15 pin PS/2 Keyboard: Mini Din 6 pin Female PC Computer Interface PS/2 Mouse: Mini Din 6 pin Female VGA : HDDB 15pin Female PS/2 Keyboard: Mini Din 6 pin Female Cascade Port Connector PS/2 Mouse: Mini Din 6 pin Female... - Page 28 User Manual Technical Specification Item Description LCD Screen Manufacturer LCD Origin South Korea Panel 15” TFT 17” TFT Resolution 1,024 x 768 1,280 x 1,024 Brightness 250 cd/m2 Color 16.2 Million 16.2 Million Contrast Ra tio 300:01:00 350:01:00 ° ° View ing Angle x 120 Display Area...
