Summary of Contents for Jireh PIT GAGE
- Page 1 PIT GAGE PG0013 Rev 04.1 Manual Pit Inspection Tool 53158 Range Road 224 780.922.4534 Ardrossan, Alberta jireh.com Canada T8E 2K4...
- Page 2 OPERATING INSTRUCTIONS 1. Centre Base (Fig. 1-B) The centre base may be used alone or in part with multiple extension arms. 2. Extension Arms (Fig. 1-C) The extension arms may be used in any configuration. A small radius on the bottom surface assists with measuring small diameter pipes.
