- Page 1 All manuals and user guides at all-guides.com Service Guide SP-i350 SERVICE GUIDE KYE SYSTEMS CORP. SP-i350 Version : 1.0 Version : 1.0 Page 1 of 15...
-
Page 2: Revision History
All manuals and user guides at all-guides.com Service Guide SP-i350 Revision History Version Date Change 03/09/2006 Version : 1.0 Page 2 of 15... -
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Service Guide SP-i350 Table of Contents Revision History …………………………………………………………………….2 Table of Contents ……………………………………………………………………3 Getting Started ………………………………………………………………………4 Conventions Used in this Guide ……………………………………….4 Safety Precautions ……………………………………………………..4 Chapter 1. How to Handle Defective Returns……………………………………..5 1.1 Overview …………………………………………………………..5 1.2 Problems …………………………………………………………...6... -
Page 4: Getting Started
All manuals and user guides at all-guides.com Service Guide SP-i350 Getting Started Conventions Used in this Guide Pay Special Attention : Instructions that are important to remember and may prevent mistakes . Caution : Information that, if not followed, may result in damage to the product . -
Page 5: Chapter 1. How To Handle Defective Returns
All manuals and user guides at all-guides.com Service Guide SP-i350 Chapter 1. How to Handle Defective Returns 1.1 Overview Receiving Defective speakers from Customers Verifying problems Proceeding necessary tests Function NG Analyzing possible malfunction causes Deciding & proceeding the Function NG... -
Page 6: Problems
All manuals and user guides at all-guides.com Service Guide SP-i350 1.2 Problems Item Problem Description 1.2.1 One or more channels no sound 1.2.2 Power LED (indicator) no light 1.2.3 Volume no function Version : 1.0 Page 6 of 15... -
Page 7: One Or More Channels No Sound
All manuals and user guides at all-guides.com Service Guide SP-i350 Attention Please follow the numbered sequence marked within parenthesis given in individual Flow chat, in that this is the best-recommended sequence to rectify the problems . 1.2.1 One or more channels no sound... -
Page 8: Power Led (Indicator) No Light
All manuals and user guides at all-guides.com Service Guide SP-i350 1.2.2 Power LED (indicator) no light Power LED (indicator) no light Problem DC cord of transformer Analyzer and Defective,IC3 Power switch or LED defective disconnected or defective Identify the Causes... -
Page 9: Chapter 2. Specifications
All manuals and user guides at all-guides.com Service Guide SP-i350 Chapter 2. Specifications NO. Description Unit Specifications ≧ 5 Out Power at THD 10% 400 ± 50 Sensitivity Freq. Response (Ref:-3dB) Hz 35Hz ~ 20KHz dB ≧ 40 Separation dB 70 ± 5 S/N ratio mV ≦... -
Page 10: Chapter 3. Block Diagram
All manuals and user guides at all-guides.com Service Guide SP-i350 Chapter 3. Block Diagram Volume R.CH Speaker Power Increase Amplifier AUDIO IN Volume L.CH Speaker Decrease Power AC IN Conditioner Version : 1.0 Page 10 of 15... -
Page 11: Chapter 4. Exploded View
All manuals and user guides at all-guides.com Service Guide SP-i350 Chapter 4. Exploded View Host Satellite Version : 1.0 Page 11 of 15... -
Page 12: Chapter 5. Part List
5 IC, TDA2007A 1-100-07 6 IC, NE555N 9-100-03 7 IC, PT2256 9-100-04 8 TPR rubber foot(round), SP-i350 9-100-05 9 TPR rubber foot(straight ), SP-i350 9-100-06 10 SP-i350/Body/Satellite(Black) 9-101-04 11 SP-i350/Body/Satellite(White) 9-101-05 11 Adaptor, 120V:13.5VAC & 0.85A 9-100-07 12 Adaptor, 220V:13.5VAC & 0.85A-A 9-100-08 13 Adaptor, 220V:13.5VAC &... - Page 13 All manuals and user guides at all-guides.com Service Guide SP-i350 24 Carton, SP-i350 1/10 9-102-05 25 Manual, SP-i350 9-102-06 26 PE Bag, SP-i350/Gift Box 9-102-08 Version : 1.0 Page 13 of 15...
-
Page 14: Chapter 6. Schematic Diagram
All manuals and user guides at all-guides.com Service Guide SP-i350 Chapter 6. Schematic Diagram Version : 1.0 Page 14 of 15... -
Page 15: Chapter 7. Important Notes
All manuals and user guides at all-guides.com Service Guide SP-i350 Chapter 7. Important Notes 7.1 Packing Requirement for Sending the PCB Assembly by Post PCB assembly is a kind of sophisticated electronic circuit board. Well packing will be required when sending them by post.
