- Page 1 VISOCALL IP. Connection Module SM-B. User Manual. HEALTH CARE www.schrack-seconet.com...
- Page 2 Connection Module SM-B. Diagnostic socket (5 pin DIN) Socket for push button (RJ45) LED finder light for presence or cancel key Presence or cancel key Call key LED finder light for call key CAUTION: It must be checked that the push button is fully functional each time...
- Page 3 (see sketch below). Cleaning and Disinfection Membrane keypad with call and cancel key For the SM-B connection module, without exception only use disinfectants that do not This membrane keypad consists of a contain ketones or esters either in part or in full.
- Page 4 SCHRACK SECONET AG Eibesbrunnergasse 18 A-1122 Vienna Tel.: +43-1-81157-0 office@schrack-seconet.com Czech Rep. • CZ-100 00 Prague 10, V Úz ˇ labine ˇ 1490/70 • Tel.: +420-2-74782284 Hungary • HU-1119 Budapest, Fehérvári út 89-95 • Tel.: +36-1-4644300 India • IN-122002 Gurgaon, Technopolis, DLF Golf Course Road, Sector-54 • Tel.: +91-124-4626248 Poland •...
