- Page 1 142-1850 40 INCH SPIKER For Serial Nos. 413,950,474 & Higher Part No. 4506-687 Rev. A...
- Page 2 ©2023 Z Turf Equipment is part of the Contact us at www.zturfequipment.com. Exmark® family of products Printed in the USA...
-
Page 3: Introduction
Write the numbers in the space provided. CONGRATULATIONS on the purchase of your Z Turf Equipment accessory. This product has been carefully designed and manufactured to give you a maximum amount of dependability and years of trouble-free operation. -
Page 4: Table Of Contents
Contents Introduction ............3 Safety ..............5 Safety Alert Symbol ......... 5 General Safety ..........5 Safety and Instructional Decals ....... 6 Specifications ............7 Systems ............7 Dimensions............. 7 Setup ..............8 Accessory Removal ......... 8 Install Accessory ..........8 Operation ..............10 Controls ............10 Before Operation ...........10... -
Page 5: Safety
Safety Safety can not read this manual, it is the owner’s responsibility to explain this material to them; other languages may be available on our website. Safety Alert Symbol • Only allow trained, responsible, and physically capable operators that are familiar with the safe This Safety Alert Symbol (Figure 2) is used both in operation, operator controls, and safety signs and this manual and on the machine to identify important... -
Page 6: Safety And Instructional Decals
Safety Safety and Instructional Decals decal120-9570 120-9570 1. Warning—stay away from moving parts, keep all guards and shields in place. decal121-6162 121–6162 1. Cutting/dismemberment hazard of hand or foot, tines—lower the tines to the ground; read the Operator’s Manual for disassembly procedure. decal133-8061 133-8061... -
Page 7: Specifications
Specifications Specifications Systems Spiker 18 Rows of spikes Dimensions Overall Width: 46 inches (117 cm) Overall Length: 31 inches (79 cm) Overall Height: 22 inches (56 cm) Weight: 305 lb (138 kg) -
Page 8: Setup
Setup Setup Accessory Removal Remove any mid-mount accessory that is currently installed on the machine; refer to the Z-Aerate Operator’s manual and the installed accessory Operator’s manual for instructions. Install Accessory Position the rear wheel of the Z-Aerate machine g348159 Figure 4 to the middle of the accessory and slowly start turning the machine over the accessory (see... - Page 9 Setup g348280 Figure 6 Left side shown 1. Lift arm assembly 3. Swivel chain assembly 2. Lynch pin Using the hydraulic cylinder, raise or lower the lift arm center linkage until the ball swivel aligns with the mounting holes in the rear frame of the accessory.
-
Page 10: Operation
Operation Operation safely perform the job. Only use accessories and attachments approved by Z Turf Equipment. Note: Determine the left and right sides of the • Inspect the area where the machine is to be machine from the normal operating position. -
Page 11: Operating The Accessory
Operation Important: Keep the drive tires on the ground • Operate the machine only in good visibility and appropriate weather conditions. Do Not operate at all times to maximize lateral machine stability the machine when there is the risk of lightning. and dethatching quality. - Page 12 Operation g298889 Figure 9 1. Turning away from accessory...
-
Page 13: Maintenance
Unauthorized modifications to the original equipment or failure to use The engine can become very hot. Touching a original Z Turf Equipment parts could lead hot engine can cause severe burns. to serious injury or death. Unauthorized... -
Page 14: Periodic Maintenance
Maintenance Periodic Maintenance Cleaning Check the Spiker Blades and Cleaning and Storing Safety Bearings • Park machine on level ground, disengage drives, set parking brake, stop engine, and remove key. Service Interval: Before each use or daily Wait for all moving parts to stop before leaving the operator’s position. -
Page 15: Information
While the exposure from Z Turf Equipment products may be negligible or well within the “no significant risk” range, out of an abundance of caution, Z Turf Equipment has elected to provide the Prop 65 warnings. Moreover, if Z Turf Equipment does not provide these warnings, it could be... - Page 16 Engine Model No. and Spec. No. Model No. Engine Serial No. (E/No) Serial No. ©2023 Z Turf Equipment is part of the Exmark® family of products All Rights Reserved Printed in the USA 415 Industrial Row • Beatrice, NE 68310 • (402) 223-6300 www.zturfequipment.com...
