Nordson NF-C3 User Manual

Nordson NF-C3 User Manual

Surface mount metal infrared exit button
Hide thumbs
1
2

Advertisement

Table of Contents

Product Features & Technical Specifications
NO/NC/COM Single pole architrave switch with LED Status
• Sensor: infrared adjustable 3-15cm
• Input Power: 12-24vdc
• Contact Rating: 24vdc 2A
• Output Contact: Single Pole
NO/NC/COM
• Mechanical Life – 500,000
Power Supply & Connections
A permanent 12-24 VDC supply is required to operate the touchless series of Exit
Buttons.
Blue
1
R
NF-C3 Surface Mount Metal
Infrared Exit Button Use Manual
• IP rating: IP68( ( O ptional) )
• Surface mount
• Operating temperature: -20°C to 55°C
• Operating humidity: 0-95%
• LED Status
Blue
= Standby
Green
= Activated
12V DC
Adapter
Your Safety , We Care
www.chinanordson.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NF-C3 and is the answer not in the manual?

Questions and answers

Related Manuals for Nordson NF-C3

Summary of Contents for Nordson NF-C3

  • Page 1 Your Safety , We Care NF-C3 Surface Mount Metal Infrared Exit Button Use Manual Product Features & Technical Specifications NO/NC/COM Single pole architrave switch with LED Status • IP rating: IP68( ( O ptional) ) • Sensor: infrared adjustable 3-15cm •...
  • Page 2 Your Safety , We Care Activation Distance The Exit button has sensitivity adjustment from 3-15cm this can be adjusted as follows: Activation Distance Turn left to reduce activation distance Turn right to increase activation distance Note: DO NOT face the infrared sensor directly into the sunlight, as this will affect the performance of the unit.
