- Page 1 MS-HBT44B70 4×4 HDMI 18Gbps Over HDBaseT Matrix SEADA S h o w i n g t h e W o r l d VER 1.1...
-
Page 2: Table Of Contents
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
④ 6× Mounting Ears (Receiver) ⑤ 4× Phoenix terminals (male) ⑥ 8× Wideband IR Receiver cables ⑦ 8× Wideband IR Blaster cables ⑧ 1× 24V/2.7A Locking Power Adaptor ⑨ 1× IR Remote control ⑩ 1× User Manual Website: www.seada.co.uk 1/13 E-mail: sales@seada.co.uk... -
Page 4: Specifications
1×IR Out [3.5mm Stereo Mini-jack] 1×RS-232 [Phoenix connector] Mechanical Chassis Material Metal Silkscreen Color Black TX: 360mm (W)×160mm (D)×35mm (H) Dimensions RX: 115mm(W)×65mm(D)×17mm(H) Weight TX: 1.9kg, RX: 206g Power Supply DC 24V/2.7A Power Consumption 35W(max) / 1W（Standby） Website: www.seada.co.uk 2/13 E-mail: sales@seada.co.uk... -
Page 5: Operation Controls And Functions
Connect to the HDMI display devices, such as TVs HDMI or Monitors. Connect to HDBaseT receiver comes from the OUTPUT same package. Don't connect to a projector directly HDBaseT that built-in HDBaseT input port since 24V POC may destroy this projector. Website: www.seada.co.uk 3/13 E-mail: sales@seada.co.uk... - Page 6 1080p,Stereo Audio 2.0 1080p,Dolby/DTS 5.1 1080p,HD Audio 7.1 1080i,Stereo Audio 2.0 1080i,Dolby/DTS 5.1 1080i,HD Audio 7.1 3D,Stereo Audio 2.0 3D,Dolby/DTS 5.1 3D,HD Audio 7.1 4K2K30_444,Stereo Audio 2.0 4K2K30_444,Dolby/DTS 5.1 4K2K30_444,HD Audio 7.1 4K2K60_420,Stereo Audio 2.0 4K2K60_420,Dolby/DTS 5.1 Website: www.seada.co.uk 4/13 E-mail: sales@seada.co.uk...
-
Page 7: Hdbaset Receiver Panel
Channel 1 IR Receiver. Connect with Wideband IR IN IR Rx. Channel 2 IR Transmitter. Connect with IR OUT Wideband IR Tx. Connect to a PC or control system with phoenix RS-232 jack for transmission of RS-232 commands. Website: www.seada.co.uk 5/13 E-mail: sales@seada.co.uk... -
Page 8: Ir Control System
This is accomplished by placing a series of IR Emitters on devices to control and IR Receivers at all locations you wish to control from to enable the IR signal to travel both ways via the single Cat5e/ 6/7 cable. Website: www.seada.co.uk 6/13 E-mail: sales@seada.co.uk... - Page 9 Attention: The matrix has one location HDMI output. If the HDMI input source is switched to the one location HDMI output, the HDMI output end has not control the matrix through IR. The function of the IR “ALL” port is control about one to all port. Website: www.seada.co.uk 7/13 E-mail: sales@seada.co.uk...
-
Page 10: Remote Control
② Press these keys to select the output A, output B, output C or output D for output corresponding 1, 2, 3 or 4 input source. Output B Output C Output D HDMI Matrix Remote Website: www.seada.co.uk 8/13 E-mail: sales@seada.co.uk... -
Page 11: Web Gui User Guide
Then select the “TCP Control Mode” port, click the “Search” button. At this moment, you can get current IP address. You can set the IP address to your PC/laptop/mobile Internet Explorer and click “Search” to enter Web GUI page. The Web GUI likes below: Website: www.seada.co.uk 9/13 E-mail: sales@seada.co.uk... - Page 12 Close this switch, it will mute. ④ Click this button will reboot device. ⑤ Click this button will set to factory reset. Control page ① Select the input source to the output port. ② Select the output port audio. Website: www.seada.co.uk 10/13 E-mail: sales@seada.co.uk...
- Page 13 EDID mode status. Status page ① Network Configuration ◆ In DHCP open status: HDCP switch: Obtian the network configuration information, including IP address, Subnet, Gate. Then click “Save Changes” button to save DHCP status. Website: www.seada.co.uk 11/13 E-mail: sales@seada.co.uk...
- Page 14 Net Status button: Press this button refresh current network configuration information to display in the status log. In this unit, Mac address can check only, you can not set it. ② Display the network configuration information. Upgrade page ① Open upgrade file to upgrade. Website: www.seada.co.uk 12/13 E-mail: sales@seada.co.uk...
-
Page 15: Application Example
10. Application Example RS-232 Equipped/HDMI Matrix UHDTV Computer Receiver Transmitter Power Supply DVD or Blu-ray Player Active Speakers Website: www.seada.co.uk 13/13 E-mail: sales@seada.co.uk...
