iDance XD 101 - Portable 3 in 1 Party Machine Manual

PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATION THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

IMPORTANT SAFETY INSTRUCTIONS

  1. Read these instructions.
  2. Keep these instructions. Heed all warnings.
  3. Follow all instructions.
  4. Do not use this apparatus near water.
  5. Clean only with dry cloth.
  6. Do not block any ventilation openings.
  7. Install in accordance with the manufacturer's instructions.
  8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  9. Do not defeat the safety of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety purpose. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
  10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
  11. Only use attachments/accessories specified by the manufacturer.
  12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacture, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over. Portable Cart Warning
  13. Unplug this apparatus during lightning storms or when unused for long periods of time.
  14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture does not operate normally, or has been dropped.
  15. The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.
  16. The battery shall not be exposed to excessive heat such as sunshine, fire or the like.
  17. The MAINS plugs used as the disconnect device, which shall remain readily operable.

WHAT'S IN THE BOX

WHAT'S IN THE BOX

CONNECTION

CONNECTION

Front panel

Front and Back panel

  1. Power On/Off, Disco LED: Press this button to turn On XD101
    At On state, tap this button to turn on/off disco lighting.
    Press and hold this button to turn Off XD101
  2. Voice Changer: Press this button to switch between different voice effect on microphone
    (Hi Pitch > Low Pitch > Robot 1 > Robot 2, Hold to turn off voice changer)
  3. Scratch A/B/C/D: Press this button to switch between 4 sound banks on jog wheels.
  4. Mic Echo: Press this button to select echo level on microphone
    (No Echo > Echo lv1 > Echo lv2 > Echo lv3 > Echo lv4 )
  5. Master volume: turn this knob to increase / decrease master speaker output volume
  6. Jog Wheels: The Left & Right DJ jog wheels, turn this jog wheel to trigger different built in sound to mix with your music. You may select different jog wheel sounds with the Scratch A/B/C/D button.
  7. Jingle: press this button to trigger the built-in jingle sounds.
    #1-4: Drum #5-8: Voices (each button contains 2 sounds)
  8. Intelligent Crossfader: after connecting your tablet to XD101, and run the "MixVibes" DJ application. You could use this crossfader to mix the music between Deck A and Deck B by sliding the fader.
    (Note: Headphone signal is reverse to the crossfader position. e.g When fader is on Deck A, Deck B will be played on headphone.)
  9. Master output speaker
  10. Disco LED: Press the "Disco LED" button to turn On/Off the Disco LED lighting

Back panel

  1. Tablet input: Connect your iPad / iPhone or Android tablet to this port with the included RCA to mini jack adapter cable for DJ application
  2. DC Power input: Connect the included DC 6V800mA power adapter to this socket when XD101 is NOT operated with AA batteries.
  3. Aux-Out: mini-jack output for connecting to external speaker system with bigger sound.
  4. Mic-In: Connect the include XD101 microphone to this port,
    (Note: There is 2 buttons on XD101 microphone, and you may press the button to trigger the built-in jingle / voice while you sing)
  5. Headphone Output: Connect mini jack earbud / headphone to this port to monitor cue signal for DJ application
    (Note: Headphone signal is reverse to the crossfader position. e.g When fader is on Deck A, Deck B will be played on headphone.)

Powering the XD101

  1. By Batteries
    Flip the XD101 and unscrew the battery compartment, insert 4x AA batteries in order to power up the XD101
  2. By AC adapter
    Plug the included DC6V 800mA to main power and connect the plug to XD101 when there is NO batteries inside XD101.

Mix Like a Professional DJ!

The XD101 is designed for beginner DJ and you could mix like a Pro DJ with XD101 and a tablet.

XD101 works with MixVibes (http://www.mixvibes.com/) CrossDJ iOS / Android application.

Notes: You have to purchase an in-app feature "external audio set" from CrossDJ in order to make it workable with XD101 Otherwise, you won't be able to select Mixer mode.

Follow below steps and get your tablet (iPad / Android) ready:

Step 1: Go to App store (iOS) or GooglePlay (Android) and download the MixVibes CrossDJ application.

www.apple.com
play.google.com

Step 2: Play the app and connect your tablet earphone output to XD101's tablet input as indicated on above session.

Step 3: Place and rest your tablet on the XD101 cradle stand like below

Step 4: In the CrossDJ app, click setting icon
Mix - Step 1

Step 5: In the setting page, click "advanced setting"
Mix - Step 2

Step 6: At the "Mode" session, select Mixer
(Don't select Normal or Split or the crossfader won't work)
Mix - Step 3

Step 7: After that, you could go back to main page and press the "+" on screen to import music to Deck A and Deck B
Mix - Step 4

Step 8: After importing music to Deck A and B, you are ready to go!! Press the play and enjoy mixing with XD101!
Mix - Step 5

SPECIFICATIONS

Power: DC 6V 800mA / 4x AA batteries

SOUND SOURCE INPUT: Aux in / Mic / Jingles

Output Power: 20W

Dimension: 45L x 24.5W x 7.5H cm

Specifications are typical, individual units might vary. They are subject to continuous improvement without notice and without incurring any obligation.

This product meets the essential requirements of Directive 1999/5/EC. http://www.idanceaudio.com/documentation/declarationofconformity/
