Blocklychain DS-104 Manual

Door sensor
Hide thumbs Also See for DS-104:
Table of Contents

Advertisement

Quick Links

Download this manual
DOOR
SENSOR
DS-104

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-104 and is the answer not in the manual?

Questions and answers

Related Manuals for Blocklychain DS-104

Summary of Contents for Blocklychain DS-104

  • Page 1 DOOR SENSOR DS-104...
  • Page 2 HELLO Thank you for purchasing Door Sensor. We are excited to bring convenience, security, and peace of mind into your home. Remote Access Control and monitor your home devices from Internet. Wi-Fi Connectivity Door Sensor connects to the Internet via Wi-Fi.
  • Page 3 How to Mount Door Sensor To mount the Door Sensor, stick the big part on the frame of the door or window. Then, place the small part on the surface opposite the big part. Maximum recommended gap between the big and the small parts is 2 cm.
  • Page 4 How to Install Download Blocklychain App Product Installation Guide Create a New Account: Click on Create Account Type your e-mail address Type your password Re-type your password Click on Create Account Check your e-mail to verify your account , then click on I'm Already Verified...
  • Page 5 Sign In: Click on Sign In Type your e-mail address Type your password Click on Sign In...
  • Page 6 To install a new device in Android, make sure the mobile Bluetooth is turned on and allowing the app to "access device's location / Bluetooth"...
  • Page 7 How to Install Device Connect Thermometer Hygrometer to a USB Type-C charger. Before continuing installation process, let's device battery get fully charged. * A solid green indicator light shows the battery is fully charged. Connect the device to a charger then click on the button on your device...
  • Page 8 Find your device from the list, then click on Connect Click on Search Wi-Fi Searching for available Wi-Fi networks Choose your Wi-Fi SSID Type your Wi-Fi password Click on Set Device Wi-Fi...
  • Page 9 If the device installation process finishes successfully, the message be displayed. Otherwise, the message will be displayed. It indicates that something went wrong and you will need to redo the installation process again.
  • Page 10 How to Monitor Your Device Back to home in app. Then, go to the BKC control Panel. Click on BKC Control Panel icon Click Devices This is Device Card...
  • Page 11 Name of the Door Sensor Device modes Last activity time Battery indicator Device dashboard Device connection indicator...

  • Page 12: Device Modes

    Device modes OPEN The small part got far from the big part, so door/window is opened. Also, a blue line blinks around the card and the last time activity is updated. CLOSE The small part is close to the big part, so door/window is closed.

  • Page 13: Device Dashboard

    Device Dashboard Clicking on the gear icon on the Door Sensor card, a pop-up window opens with 3 tabs. Monitor In Monitor tab, there are data about power consumption. Front Door Door Sensor Monitor Data Graph Config State Battery Open Data Graph In Data Graph tab, a bar chart represent power consumption during time.
  • Page 14 Config In Config tab, you can update firmware, rename device, and remove your device from BKC Control Panel. Front Door Door Sensor Monitor Data Graph Config FC:F5:C4:A5:0D:E2 Device Details Type DOOR_SENSOR Firmware Version 1.2.0 Install Time 2 August 2021 Su 5:23 Hardware Version Rename Device New Version Available...

  • Page 15: Led's Status

    LED's Status Status Indicator Description Connection 4 seconds 4 seconds Problem connecting to server 2 seconds 2 seconds Ready to install 0.2 second 0.2 second Connecting to Wi-Fi 0.1 second 0.1 second App connected to device Solid Orange Connecting to server Battery 0.2 second 0.2 second...
  • Page 16 Caution 1. Do not disassemble the product or change the batteries. 2. Do not charge the product at high temper- ature. Keep the device away from open fire to avoid explosion. 3. Improper use of your device’s battery may result in fire or explosion. Do not heat, open, puncture, mutilate, or dispose of your device or its battery in fire.
  • Page 17 6. Parts of your device are magnetic and may attract metallic items. Do not place magnetically sensitive devices, credit cards, other magnetic storage media near your device.

  • Page 18: Specification

    Specification Device Product Name Door Sensor Model DS-104 Size (big part) 7x2x2 cm Size (small part) 5x1x1 cm Weight (big part) 22 g Weight (small part) Material Communication Wi-Fi 802.11 b/g/n 2.4GHz Battery 3.7V Lithium rechargeable Charger USB Type-C...

  • Page 19: Package Content

    1x Door Sensor 1x Big Part 1x Small Part For further help or inquiries: 1) Email support@blocklychain-iot.com, or 2) Login to your account on BKC Control Panel , click , and submit a ticket. All right reserved. Copyright © 2022 Blocklychain...
