Simonds CLP-2000A Owner's And Safety Manual

Component lead processor
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

OWNER & SAFETY MANUAL
COMPONENT LEAD PROCESSOR

DIMENSIONS

WEIGHT

WORKING PRESSURES

Made in the U.S.A.
248 ELM ST. | SOUTHBRIDGE, MA 01550
508-764-3235 | sales@simonds-inc.com | www.simonds-inc.com
CLP-2000A
Read Carefully Before Operating
SIMONDS INC.
3"H X 8"L X 5 1/4"W
4.5 LBS
60-80 PSI
Wear Eye Protection

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLP-2000A and is the answer not in the manual?

Questions and answers

Related Manuals for Simonds CLP-2000A

Summary of Contents for Simonds CLP-2000A

  • Page 1 COMPONENT LEAD PROCESSOR DIMENSIONS 3”H X 8”L X 5 1/4”W WEIGHT 4.5 LBS WORKING PRESSURES 60-80 PSI Made in the U.S.A. Read Carefully Before Operating Wear Eye Protection SIMONDS INC. 248 ELM ST. | SOUTHBRIDGE, MA 01550 508-764-3235 | sales@simonds-inc.com | www.simonds-inc.com...
  • Page 2 CLP-2000A DESCRIPTION PART # PISTON HOUSING 1-F-002 PISTON SHAFT 3-2000-CLP (includes 20-CLP-2000) SPRING PLUNGER 4-CLP-2000 LOCK NUT 36-CLP COVER PLATE 6A-CLP-2000 CUTTER BLADE 7-CLP-2000 TENSION SPRING 3-CLP-K10 BASE 9A-CLP-2000 MOUNTING PLATE 10A-CLP-2000 TENSION SPRING 11A-CLP (2 required) COVER SCREWS 12-CLP-2000...
  • Page 3 An inline lubricator will help to extend the life of the tool. Only use pneumatic oil recommended • by Simonds in the lubricator. If no lubricator is available place a few drops of pneumatic oil in to the air inlet of tool each week.
  • Page 4 Dispose of tool and material as recommended by local disposal regulations. • Simonds tools are not for use other than on production line. Tool should not be used as a hammer • or pry bar. A “two hand control” may be required depending on the attached tool.
