Downloaded from www.watergardeningdirect.com
SOLAR POWERED
Pump, Panel and Remote Kit
(2150PKD-G)
CONTENTS
INSTALLATION
Ensure connectors are water tight.
1. Run pump cable through the water feature.
2. Fit the tube from the finial to the pump.
3. Screw the post to bottom of the solar panel.
4. Fit spike to the post.
5. Connect panel to the pump
Advertisement
Table of Contents
Related Manuals for Smart Solar 2150PKD-G
Summary of Contents for Smart Solar 2150PKD-G
- Page 1 Downloaded from www.watergardeningdirect.com SOLAR POWERED Pump, Panel and Remote Kit (2150PKD-G) CONTENTS INSTALLATION Ensure connectors are water tight. 1. Run pump cable through the water feature. 2. Fit the tube from the finial to the pump. 3. Screw the post to bottom of the solar panel.
- Page 2 Downloaded from www.watergardeningdirect.com POSITION Position the solar panel to receive the maximum amount of direct sunlight OPERATION BATTERY OFF SOLAR ON 4H 24H TIMER Panel is supplied with the switch in the OFF position to protect the internal rechargeable battery. The switch can be used to select between BATTERY and SOLAR modes or to switch the unit OFF.
- Page 3 Downloaded from www.watergardeningdirect.com ON 4 HOURS ON 4H Press button A on the remote control or ON 4H on the back of the solar panel to switch the pump on. Press again and the pump will switch off. The red indicator light on the back of the panel will illuminate and remain on whilst the pump is operating.
- Page 4 Downloaded from www.watergardeningdirect.com BATTERY MODE - MODE BATTERY - BATTERIE MODUS The battery has capacity for up to 8 hours of operation, 2 cycles of 4 hours. The table below shows how long on average it will take to fully charge from flat. In most cases it will not take this long as there will be charge left in the battery.
- Page 5 We suggest you do this occasionally anyway to help prolong the battery life. If after this boost charge your battery still does not perform to expectations you should seek a replacement from Smart Solar (available via our website www.sgpuk.com). All our battery packs are covered by a 1 year warranty.
