FOREDOM CC Series Owner's Manual

Flexible shaft power tools & handpieces
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
for Foredom
Flexible Shaft
Power Tools
& Handpieces
For Your Own Safety
Please read this Assembly, Operation,
•
and Service Manual before operating
your Foredom power tool.
Always wear eye protection while
•
using power tools.
Only use accessories rated for use
•
at the maximum speed (18,000 RPM)
of these power tools except with the
No. 35 Handpiece which requires
accessories rated for 35,000 RPM
or higher.
FOREDOM
www.foredom.com
®
®
Series
CC
DD
MM
S
SB
SM
SR
SRB
SRM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CC Series and is the answer not in the manual?

Questions and answers

Related Manuals for FOREDOM CC Series

Summary of Contents for FOREDOM CC Series

  • Page 1 Power Tools & Handpieces For Your Own Safety Please read this Assembly, Operation, • and Service Manual before operating your Foredom power tool. Always wear eye protection while • using power tools. Only use accessories rated for use • at the maximum speed (18,000 RPM) of these power tools except with the No.

  • Page 2: Table Of Contents

    Never operate any accessory at speeds above it’s maximum rated speed. When properly used, all of Foredom's accessories can be operated at the speed ratings listed in the Foredom Accessory Catalog or on the accessory kits and packages. Always find out the manufacturer's speed rating before using accessories other than those from Foredom.

  • Page 3: Owner's Registration Card

    3-prong grounding type plugs and 3-pole receptacles that accept the tool’s plug. A complete Foredom flexible shaft power tool consists of a motor, flexible shaft and sheath, speed control (foot or manual) and a handpiece. Locate and identify all components, parts and accessories you purchased before discarding the packing list and packing materials that came with your power tool.

  • Page 4: Foredom Power Tools

    You have purchased a fine quality power tool which will perform a wide variety of tasks difficult to do with any other kind of power tool. Foredom power tools are manufactured to high standards of precision and performance and, with proper use and regular maintenance, will give you years of trouble-free performance.

  • Page 5: Assembly Instructions

    Assembly and Adjustment of Flexible Shaft, Sheath, and Handpiece Proper assembly and adjustment of the flexible shaft and sheath are critical for the correct operation of your Foredom power tool. The exposed tip (handpiece end) of the flexible shaft (with handpiece removed) must extend 3/4″ beyond the sheath.

  • Page 6: Connecting Foot Control

    Connecting Foot Speed Control The electrical specifications for your power tool are listed on the motor name plate. It will show the proper voltage and currents to use with your power tool. Be sure to follow the grounding instructions on page 3 of this manual while attaching either the speed control or motor to a power outlet.

  • Page 7: Foredom Handpieces And Rotary Accessories

    Handpieces FOREDOM ® ®...

  • Page 8: Attaching Accessories To Handpieces

    Attaching Accessories to Handpieces Directions for attaching accessories to handpieces vary according to the type of handpiece being used. Locate the model number of your Foredom handpiece from the illustrations on the previous page. Attach the accessory according to the following: Collet Types 8, 8D, 25, 28, 28SJ, 35, 35SJ, 44T, and 44TSJ General Directions: Be sure to use the correct shank size.

  • Page 9: Handpiece Lubrication

    Clean off any dirt or old lubricant. Apply only 1 or 2 drops of Foredom oil to the spindle where it attaches to the slotted shaft. Now replace sheath connector.

  • Page 10: General Accessory Recommendations

    Grinding, sanding, carving, engraving, brushing, cutting, buffing and polishing can all be easily accomplished. Choose the right accessory for your applications from the Foredom Accessory Catalog. You may purchase accessories from your local dealer, or contact: The Foredom Electric Company, 16 Stony Hill Road, Bethel, CT 06801, (203)792-8622; or on-line at www.foredom.com.

  • Page 11: Operation - General Guidelines

    flying debris, chips, or sparks which might result from the work being done. Your Foredom motor may be operated in a vertical or horizontal position, but it should not be enclosed or confined so as to restrict air circulation. If the motor is hung up above a workbench, be sure it is fastened securely to the wall or motor hanger.

  • Page 12: Maintenance Procedures

    The shaft should be checked, wiped clean, and relubricated with grease every 50 hours of use. With every 200 hours of use, the shaft should be thoroughly cleaned with solvent and lubricat- ed. Use Foredom flex shaft grease (p/n 10006) or high quality white lubricating grease. Exposing the Inner Shaft 1.Remove handpiece...

  • Page 13: Replacement Of Worn Shafts And Sheaths

    Always make sure your power tool is unplugged when conducting maintenance procedures! Replacement of Worn Shafts and Sheaths Shafts and sheaths last longer when they are not used at sharp angles or loops, since wear occurs at the points of greatest friction. There is no way to avoid ultimate wear, and under normal condi- tions a flexible shaft machine may require several replacement shafts and sheaths during its lifetime.

  • Page 14: Special Operation Instructions For Sr, Srb & Srm Motors

    (Part No. 2019P), and an instruction manual Repair Services Authorized repair service is available at the Foredom factory in Bethel, CT. Send items for repair to the factory marked “Attention: Repair Department” The Foredom Electric Company, 16 Stony Hill Road, Bethel, CT 06801. Enclose the item(s), a packing list, and information regarding the problem or repairs required.

  • Page 15: Recommended Spare Parts And Supplies

    Many excellent books on wood carving and power carving techniques and accessories are avail- able from your dealer, woodcarving clubs, and your local library. Foredom offers a large variety of all types of accessories used by wood, plastic and stone carvers. Request a catalog or visit Foredom on-line at www.foredom.com.

  • Page 16: Other Service And Repair

    Series CC, DD, MM, S, SB, SM, SR, SRB, and SRM Flexible Shaft Power Tools Foredom warrants the S and CC Series Motors to be free of defects in material or work- manship for a period of 1 year after purchase. During the warranty period, the defective product will be repaired or replaced without charge or, at our option, the purchase price will be refunded.
