- Page 1 MULTI-FUNCTION JOYSTICK 467018B2 Software rel. 1.0.x INSTALLATION, USE AND MAINTENANCE...
-
Page 2: Table Of Contents
This manual is an integral part of the equipment to which it refers and must accompany the equipment in case of sale or change of ownership. Keep it for any future reference; ARAG reserves the right to modify product specifications and instructions at any moment and without notice. -
Page 3: Risks And Protections
DO NOT WORK IN THE VICINITY OF THE DISTRIBUTION AREA WHILE THE SYSTEM IS OPERATING. PRODUCT DESCRIPTION Explorer 2 is a multi-function joystick that, suitably configured by the computer in your possession, allows you to manage the main functions of a crop sprayer (spraying and hydraulics) directly from the hand grip. -
Page 4: Package Content
INSTALLATION PACKAGE CONTENT 1. Explorer 2 Joystick 2. Sleeve and locking nut 3. ISOBUS adapter cable Fig. 1... -
Page 5: Installation
INSTALLATION INSTALLATION - Do NOT install the device in areas where it would be subjected to excessive vibrations or shocks, to prevent any damage or accidental use of the control keys. - Install the device in a visible position within easy reach by hand; bear in mind that it should not obstruct the operator’s freedom of movement or block his/her view. -
Page 6: Wiring Connections
• Use of unsuitable cables not provided by ARAG automatically voids the warranty. • ARAG is not liable for any damage to the equipment, persons or animals caused by failure to observe the above instructions. General precautions for a correct harness position •... -
Page 7: Object Pool
R e s e t t o A r a g f a c t o r y d e f a u l t s valve input" in page 2. Fig. 9 Reset to Arag factory defaults - Allows restoring the device to factory default settings. - Page 8 8.2.1 Keys configuration (input) The device allows customized functions assignment via two modes: In the D u a l mode [type 6]: - A "dual" auxiliary input, which is a pair of keys, must be associated to a "dual" function (for example "Open/close valve"). - A "single"...
-
Page 9: Isobus
8.4.1 Automatically loading ARAG functions The Explorer 2 Joystick connected to an ARAG ECU (compatible with version 3.4.1 or later) allows the automatic implementation of the preset ARAG functions. After the first configuration the Virtual Terminal may ask for the auxiliary joystick to be enabled. - Page 10 SETTING 8.4.3 Key map for custom association The KEY MAP below is useful to manually assign the functions to the joystick keys. D u a l • MODE Joystick with 1 page PAGE 1 Joystick with 2 pages PAGE 1 PAGE 2 S i n g l e •...
-
Page 11: Test Keys
SETTING T e s t k e y s T e s t k e y s Press the keys one at a time: on the VT, ensure that the pressure of the key corresponds to the actual action (the corresponding key lights up). Fig. -
Page 12: Switching On
SWITCHING ON • Function test After start-up, the joystick performs a function test as follows: backlighting of keyboard and 1 long vibration. The device accesses the functions in the main page, page 1. SIGNAL: LED AND VIBRATIONS When each key is pressed, the device vibrates (1 short vibration). B key LED Main Status LED... -
Page 13: Maintenance / Diagnostics / Repairs
MAINTENANCE / DIAGNOSTICS / REPAIRS - TECHNICAL DATA MAINTENANCE / DIAGNOSTICS / REPAIRS • Clean only with a soft wet cloth. • Do not use aggressive detergents or products. • Do not clean equipment with direct water jets. TECHNICAL DATA 12.1 Electrical features Power supply voltage .......... -
Page 14: End-Of-Life Disposal
Dispose of the system in compliance with the established legislation in the country of use. GUARANTEE TERMS 1. ARAG s.r.l. guarantees this apparatus for a period of 360 days (1 year) from the date of sale to the client user (date of the goods delivery note). - Page 16 Only use genuine ARAG accessories or spare parts to make sure manufacturer guaranteed safety conditions are maintained in time. Always refer to the Internet address www.aragnet.com Via Palladio, 5/A 42048 RUBIERA (Reggio Emilia) - ITALY Tel. +39 0522 622011 Fax +39 0522 628944 http://www.aragnet.com...
