Summary of Contents for Ronbow Taylor 602718-FINISH
- Page 1 INSTALLATION AND CARE GUIDE STYLE WOOD FRAME LED MIRROR 602718-FINISH...
- Page 2 FIELD CONNECTION CIRCUIT BREAKER LED MIRROR CABINET Red = Positive Red = Positive 120VAC 20A GFI White = Negative White = Negative Black = Ground Black = Ground MATERIALS INCLUDED wood frame LED mirror anchor wood screws INSTALLATION SHEET ronbow.com 170714...
- Page 3 See Figure 2. Step 3: Install the screw to the anchor. Leave at least 3/16” of screw head protruding out from the wall. Figure 3. wall See Figure 3. screw anchor INSTALLATION SHEET ronbow.com 170714...
- Page 4 Connect the transformer connector to the mirror then connect the wire of the mirror to the electricity source of your home. Then line up the key-holes behind the mirror and let the mirror rest onto the screws. See Figure 5. transformer connector INSTALLATION SHEET ronbow.com 170714...
