- Page 1 INSTALLATION AND CARE GUIDE MARQUEE FRAMELESS LED MIRROR 600718-FINISH...
- Page 2 Red = Positive 120VAC 20A GFI White = Negative White = Negative Black = Ground Black = Ground MATERIALS INCLUDED frameless LED mirror set of z-cleat wood screws MATERIALS NEEDED 2 x 4 cut to size INSTALLATION SHEET ronbow.com 170728...
- Page 3 Step 2: Figure 2. Place a 2 x 4 supporting beam behind the wall of the desired location Open up a hole on the wall to allow the wire to connect to the mirror. See Figure 2. INSTALLATION SHEET ronbow.com 170728...
- Page 4 See Figure 3. Step 5: Connect the transformer connector to the mirror then connect the wire of the mirror to the electricity source of your home. Then line up the Z-cleat and hang the mirror to the wall. INSTALLATION SHEET ronbow.com 170728...
