U s e r M a n u a l
CAM-21
PRODUCT FEATURES:
Image Sensor: 1099 HD CCD
TV Lines: 560
Resolution: 976 x 496
Minimum Illumination: 0.1 Lux
TV System: NTSC
Waterproof Rating: IP68
Horizontal Angle: 170 Degrees
Vertical Angle: 120 Degrees
Parking Lines: Yes (Removable)
Image Adjustment: Yes (Mirror/Normal)
Enhanced Performance In Low Light: Yes
Video Output: 1.0V p-p 75ohm
Operating Voltage: 12V DC (Negative Ground)
Current Consumption: 120mA @ 13.8V
Operating Temperature: -20 Degrees C to +70 Degrees C
DISCLAIMER:
Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installation.
Please ensure you use the correct tools to avoid damage to the vehicle or product.
Connects2 can not be held responsible for the installation of this product.
Technical Support
Connects2 want to provide a fast and suitable resolution should you encounter any
technical issues. With this in mind, when contacting Connects2, try to provide as
much Information as possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: support.connects2.com
www.c2vision-eu.com
Universal Camera
Threaded Smooth Surface Mount with Fixed Angle
Advertisement
Table of Contents
Related Manuals for Connects2Vision CAM-21
Summary of Contents for Connects2Vision CAM-21
- Page 1 U s e r M a n u a l CAM-21 Universal Camera Threaded Smooth Surface Mount with Fixed Angle PRODUCT FEATURES: Image Sensor: 1099 HD CCD TV Lines: 560 Resolution: 976 x 496 Minimum Illumination: 0.1 Lux TV System: NTSC...
- Page 2 CONTENTS Connects2Vision • Camera with 1m cable to mini Male 6 pin connector • 1m camera connection cable to mini Female 6 pin connector and RCA Female connector • 6m RCA Male to Male extension cable • Instructions INSTALLATION 1. Connect the Black wire to a suitable ground and the Red wire to a switched +12V supply.
