It is essential to read through these instructions before putting the fan into operation.
This operating instruction is valid for the fan-shaped awnings
with different masses and opening angles
Errors and technical changes are reserved. Radius accepts no liability
whatsoever in the event of incorrect operation or improper use of the products.
Radius will replace or repair defective products within the scope of the
warranty conditions at the time of delivery. Radius accepts no further liability.
We reserve the right to make design changes.
Our GTCs apply.
O p e r a t i n g i n s t r u c t i o n s _ O - F A N _ F i n a l . d o c x
Operating instructions
Radius International AG
Solothurnerstrasse 43
CH-3296 Arch bei Büren
info@radius-delta.com
http://radius-delta.com/
S e i t e 1 v o n 8
Advertisement
Table of Contents
Related Manuals for Radius O-Fan
Summary of Contents for Radius O-Fan
- Page 1 Solothurnerstrasse 43 Radius will replace or repair defective products within the scope of the CH-3296 Arch bei Büren warranty conditions at the time of delivery. Radius accepts no further liability.
- Page 2 Operating instructions Table of contents: Safty requirements ............................3 Explanation of symbols and notes ..................... 3 General safety instructions ........................ 3 Use of the fan-shaped awning ......................3 Operating instructions ........................... 4 Inserting the sunshade into the holder ..................... 4 Opening and aligning the........................
- Page 3 Operating instructions Safty requirements Explanation of symbols and notes Warning Warning of dangerous situation; possible consequences: Death or most serious injuries. Caution Attention to dangerous situation; possible consequences: light or minor injuries. Attention Warning of harmful situation; possible consequences: the product or something in its environment may be damaged.
- Page 4 Operating instructions Operating instructions Inserting the sunshade into the holder a.) Hook the crank handle into the ring for weighting b.) Insert the fan and move slightly until "click" engages c.) Hook the crank handle into the eyebolt and tighten it slightly until the fan is fixed d.) Check that the fan is firmly seated in the holder! O p e r a t i n g i n s t r u c t i o n s _ O - F A N _ F i n a l .
- Page 5 Operating instructions Opening and aligning the a.) Release omega brake of the fan sail with crank. Brake gear side right, turn left to release! Brake gear side left, turn right to release! b.) Move the fan to the desired position by hand. c.) Loosen the fabric expander, which holds the fabric.
- Page 6 Operating instructions f.) Hand-tighten the omega brake on the ball joint with the crank to hold the fan in the desired position. Brake gear side right, turn left to release! Brake gear side left, turn right to release! Closing the a.) Release the omega brake and set the fan at an angle.
- Page 7 Operating instructions e.) Fix fabric expander f.) Roll up fabric g.) Move the fan to the parking position h.) Hand-tighten the omega brake Repositioning the fan a.) Loosen the eyebolt by means of the hand crank. b.) Hook hand crank into ring c.) Remove fan secured d.) Put it to a dry or another secured location O p e r a t i n g i n s t r u c t i o n s _ O - F A N _ F i n a l .
- Page 8 Operating instructions Wind compatibility In case of increasing wind at maximum 30 km/h close the fan. Do not allow the fabric to flutter when closed. Secure with fabric expander. O p e r a t i n g i n s t r u c t i o n s _ O - F A N _ F i n a l . d o c x S e i t e 8 v o n 8...
