These operating instructions are valid for the belalatus® fan-shaped
awnings with different dimensions and opening angles
Table of contents:
1
Safety requirements ...................................................................................................................................... 2
1.1
Explanations of symbols and notes .................................................................................................. 2
1.2
General safety instructions ............................................................................................................... 2
1.3
Using the fan ..................................................................................................................................... 3
1.4
Scope of delivery ............................................................................................................................... 4
1.5
Customer accomplishment ............................................................................................................... 4
1.6
Options .............................................................................................................................................. 4
2
Operation....................................................................................................................................................... 5
3
Operation with a smartphone-app ................................................................................................................ 5
3.1
Pairing with the Radius smartphone-app ........................................................................................ 5
3.2
Opening and closing the fan ............................................................................................................. 6
3.3
Favorite ............................................................................................................................................. 6
3.4
Additional information ..................................................................................................................... 7
4
Operation with a radio handled transmitter ................................................................................................. 7
5
Operation with SOMFY Telis RTS ................................................................................................................... 8
6
Troubleshooting ............................................................................................................................................ 9
O p e r a t i n g i n s t r u c t i o n s
Operating instructions Radius belalatus® ten fan-
shaped awning
- B e l a l a t u s ten_ v 0 1 . d o c x
for end users
S e i t e 1 v o n 9
Advertisement
Table of Contents
Related Manuals for Radius Belalatus ten
Summary of Contents for Radius Belalatus ten
-
Page 1: Table Of Contents
Customer accomplishment ....................... 4 Options .............................. 4 Operation............................... 5 Operation with a smartphone-app ........................ 5 Pairing with the Radius smartphone-app ..................5 Opening and closing the fan ......................6 Favorite ............................. 6 Additional information ........................7 Operation with a radio handled transmitter ....................7 Operation with SOMFY Telis RTS ........................ -
Page 2: Safety Requirements
Operating instructions Radius belalatus® ten fan- shaped awning for end users Safety requirements Explanations of symbols and notes Warnings Attention General notes General safety instructions Together with the technical information for installation and operation, the safety regulations form the basis for the safe use of the fan. They must be read, followed and kept for later use before the fan is installed and used. -
Page 3: Using The Fan
Only use the sunblind in an undamaged condition and pay attention to possible faults. Arrange for its professional repair before further use! Only use original Radius accessories and spare parts to ensure safety, unadulterated comfort and flawless function. ... -
Page 4: Scope Of Delivery
Operating instructions Radius belalatus® ten fan- shaped awning for end users Scope of delivery An electrically operated fan consists of the following components: 1. Fan-shaped awning 2. Control module (control box, remote control and power cable) 4. Sun and wind sensor 3. -
Page 5: Operation
Pairing with the Radius smartphone-app The Radius app can be downloaded free of charge from the Apple Store under Radius Control. When using the app for the first time or resetting it, you can proceed step by step using the menu navigation. -
Page 6: Opening And Closing The Fan
Operating instructions Radius belalatus® ten fan- shaped awning for end users Opening and closing the fan The fan awning can be easily moved to the desired position via the start screen on the app. rotating fan- in and -out tilting The fan moves in this direction as long as the button is pressed. -
Page 7: Additional Information
Additional information By selecting the "add" button on the control menu, another Radius fan can be selected by standing near this fan to ensure a strong radio connection (indicated by the green bars). Additional fans can be connected during installation in the menu sequence "Connect to another sunscreen? "menu... -
Page 8: Operation With Somfy Telis Rts
If the system has been opened with the Somfy remote control or automatically with the wind and sun sensor, it is no longer possible to move with the Radius App or Vibradorm remote control for the next 4 minutes. This can be avoided by briefly pressing the stop button (my). -
Page 9: Troubleshooting
Error Pulse direction wrong: Disconnect the system from the mains for approx. 15 seconds and reconnect it to the mains. If it still does not work, the Radius installer should be notified for rectification. If the current fails while the control inputs are active, it cannot be excluded that an initialization must be done.
