Brigade SS-H002 Quick Installation Manual

4
Specifications
Spécifications/Spezifikationen/Specifiche/
Especificaciones/Specificaties/Especificações/
Спецификация/Özellikler/Specyfikacja
EN
TV system NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
< _ 0.75A @ 12Vdc
Current consumption
Power 12~24Vdc input
Inputs 2 x camera
Dimensions 147(w) x 37(h) x 78(d)mm
5.8(w) x 1.46(h) x 3.0(d) inches
Operating temperature -30°C - +80°C / -22°F - +176°F
DE
TV-System NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
< _ 0.75A @ 12Vdc
Stromverbrauch
Stromaufnahme 12~24Vdc input
Eingänge 2 x Kamera
Abmessungen 147(w) x 37(h) x 78(d)mm
5,8(w) x 1,46(h) x 3,0(d) inches
Betriebstemperatur -30°C - +80°C / -22°F - +176°F
ES
Sistema de TV NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
< _ 0.75A @ 12Vdc
Consumo de corriente
Suministro de corriente 12~24Vdc input
Inputs 2 x cámara
Dimensiones 147(w) x 37(h) x 78(d)mm
5,8(w) x 1,46(h) x 3,0(d) inches
Temperatura de servicio -30°C - +80°C / -22°F - +176°F
PT
Especificações
Sistema de TV NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
< _ 0.75A @ 12Vdc
Consumo actual
Fornecimento de corrente 12/24Vdc entrada
Entradas 2 x cámara
Dimensões 147(w) x 37(h) x 78(d)mm
5,8(w) x 1,46(h) x 3,0(d) polegadas
Temperatura de servicio -30°C - +80°C / -22°F - +176°F
TR
Ö z e i l l l k ̇ r e
Tv Sistemi NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
< _ 0.75A @ 12Vdc
Güç sarfı
Besleme 12~24Vdc input
Girişler 2 x kamera
Ebatlar 147(w) x 37(h) x 78(d)mm
5.8(w) x 1.46(h) x 3.0(d) inches
Çalışma sıcaklığı -30°C - +80°C / -22°F - +176°F
4153 SS-H002 Quick Installation Guide
SS-H002 Manual
www.brigade-electronics.com
www.brigade-electronics.com
FR
Système TV NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
courant < _
Consommation en 0.75A @ 12Vdc
Alimentation 12~24Vdc input
Entrées 2 x camera
Dimensions 147(w) x 37(h) x 78(d)mm
5,8(w) x 1,46(h) x 3,0(d) inches
Température d'utilisation -30°C - +80°C / -22°F - +176°F
IT
Sistema TV NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
< _ 0.75A @ 12Vdc
Consumo di corrente
Alimentazione 12~24Vdc input
Ingressi 2 x camera
Dimensioni 147(w) x 37(h) x 78(d)mm
5,8(w) x 1,46(h) x 3,0(d) inches
Temperature d'esercizio -30°C - +80°C / -22°F - +176°F
NL
TV-systeem NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
< _ 0.75A @ 12Vdc
Huidig verbruik
Stroomvoorziening 12~24Vdc Ingang
Ingangen 2 x camera
Afmetingen 147(w) x 37(h) x 78(d)mm
5,8(w) x 1,46(h) x 3,0(d) inches
Bedrijfstemperatuur -30°C - +80°C / -22°F - +176°F
RU
Спецификация
ТВ-система NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
< _ 0.75A @ 12Vdc
Потребляемый ток
Напряжение 12/24Vdc затраты
затраты 2 х камеры
размеры 147(ш) x 37(в) x 78(т)mm
5,8(ш) x 1,46(в) x 3,0(т) дюймов
Рабочая температура -30°C - +80°C / -22°F - +176°F
PL
Dane techniczne
System TV NTSC/PAL
AHD 1.0 (720p - 25/50/30/60 fps)
AHD 2.0 (1080p - 25/30fps)
< _ 0.75A @ 12Vdc
Natężenie prądu
Zasilanie 12~24Vdc input
Wejścia 2 x kamera
Wymiary 147(w) x 37(h) x 78(d)mm
5.8(w) x 1.46(h) x 3.0(d) inches
Zakres temperatur -30°C - +80°C / -22°F - +176°F
Руководство по быстрой установке
IG No: 7180
IG No: 7180
SS-H002
Quick installation guide
SS-H002
Guide d'installation rapide
Kurzanleitung
Quick installation guide
Guida d'installazione rapida
Guide d'installation rapide
Guía de Instalación Rápida
Kurzanleitung
Snelle installatie handleiding
Guida d'installazione rapida
Guia de instalação rápida
Guía rápida de instalación
Руководство по быстрой установке
Skrócona instrukcja obsługi
Snelle installatie handleiding
Hızlı başlangıç Kilavuzu
Guia rápida de instalação
Skrócona instrukcja obsługi
Hızlı başlangıç Kılavuzu
