What's ATSC?
ATSC, which stands for Advanced Television Systems Committee, is a broadcasting system of
terrestrial digital broadcasting. To receive ATSC, you need an antenna. An indoor antenna is able
to receive a signal, but use of outdoor antenna is recommended. You can also receive a signal by
Cable, but service may not be provided by certain Cable companies. Ask your cable company for
more information.
How to receive ATSC
In order to receive an ATSC signal, you must first run the AUTO TUNER SETUP available in the
"Interactive Plug In Menu" or regular "Menu" on your TV. When the Auto Tuner Setup is executed,
the level indicator of the Scan Menu can be set at a higher sensitivity than the normal range. In
this case, an ATSC capable channel may be set at a high level, but the real level may be too low
to receive the ATSC signal. Under these conditions, you will not be able to receive that channel. If
this happens, please follow the steps below, "How to Adjust Your Antenna" in order to receive your
channel.
How to Adjust Your Antenna
If you can not receive your requested channel, please try following the steps below to adjust your
antenna.
1. Check the RF Channel of your requested Channel, and input the channel as DCS##. (## is
the channel number which you want to receive.)
2. If you can't receive a signal, press the OK key. Then, the following banner will appear. This
channel banner appears for at least 1 minute. Pressing and holding the up/down and left/right
key will make the banner remain continuously
3. Adjust your antenna to set the signal level to the maximum.
4. Once the level indication of the banner reaches the maximum, DSC## needs to be operated
again. Then you can select your requested channel.
Downloaded from:
https://www.usersmanualguide.com/
How to best use TV models AV-56WP94 and AV-65WP94
23- 0 WWWW
Sep.10 ( Wed) 5: 06PM
1
Advertisement
Related Manuals for JVC AV-56WP94/HA
Summary of Contents for JVC AV-56WP94/HA
- Page 1 How to best use TV models AV-56WP94 and AV-65WP94 What’s ATSC? ATSC, which stands for Advanced Television Systems Committee, is a broadcasting system of terrestrial digital broadcasting. To receive ATSC, you need an antenna. An indoor antenna is able to receive a signal, but use of outdoor antenna is recommended. You can also receive a signal by Cable, but service may not be provided by certain Cable companies.
- Page 2 5. After the channel is received successfully, you then need to manually add this channel to the CHANNEL SUMMARY of the MENU. After this, the channel can be selected by up/down keys. 6. Be aware of the following: The best direction of the antenna varies according to the broadcasting stations. You can retrieve some important information such as your regional broadcasting stations, broadcasting channels, and the best direction of the antenna by inputting your address or Zip code at the following HP.
- Page 3 CC (Closed Caption) Display CC of ATSC broadcasting will be displayed correctly only when choosing FULL mode and REGULAR mode. When receiving ATSC broadcasting, the indication will be based on EIA-708. Sometimes Closed Captioning might be displayed incorrectly depending on the broadcast. Monitor out CC signals are added in this TV's Monitor out (NTSC) in order for the indications based on EIA- 608.
- Page 4 program easily or set a viewing timer using the program information sent by an ATSC broadcast. This TV can also receive content information of TV programs, too. However, sometimes the information might not be sent properly or not be displayed properly depending on the broadcasting stations.
- Page 5 GR-HD1 in DV mode. (This TV is not able to recognize DV signal .) If you have trouble when connecting 2 or more JVC D-VHS devices, please set the LINC function of JVC D-VHS to off.
- Page 6 remote. However, if you are unable to monitor the program you wish to record, please push the STOP key within the control menu of i.LINK/Timer. Once you push STOP, you should be able to record the program. This operation will be needed especially for multi-channel broadcasting situations.
