Operating Instructions
Please read and save these instructions. Read through this owner's manual carefully before
using product. Protect yourself and others by observing all safety information, warnings, and
cautions. Failure to comply with instructions could result in personal injury and/or damage to
product or property. Please retain instructions for future reference.
Description
An efficient, energy saving replacement for metal halide and high-pressure sodium fixtures,
containing an integral listed driver, the LED Large Flood Light fixtures can be easily
installed to a slip fitter.
Picture is for illustration purposes only. Your model may vary.
CONSTRUCTION
Fixture: The heavy duty cast aluminum one-piece housing is polyester powder coated and
sealed from dirt, water and insects with a hinged door with a shock-proof tempered glass.
Lens: Tempered Glass
LED Module: Copper plating provides high thermal transfer rate, minimizing the junction
temperature of the LEDs.
Finish: Dark bronze
Specifications and Dimensions
Model
Volts
39UU95
120-277V
39UU98
120-277V
39UV08
120-277V
LED Large
Flood Lights
Watts
CCT
Lumens
136W
5000K
100W
5000K
62W
5000K
39UU95, 39UU98, 39UV08
CRI
12,140
70
9,160
70
5,470
70
Dimensions (in)
H" x L" x D"
7.5" x 16.5" x 16.5"
7.5" x 16.5" x 16.5"
7.5" x 16.5" x 16.5"
