Summary of Contents for Powermat PM-ZE-45
- Page 1 USER MANUAL PLACE PHOTO HERE ELECTRIC STAPLER PM-ZE-45 ORIGINAL MANUAL...
-
Page 2: Table Of Contents
Table of Contents WARNING / INFORMATION SYMBOLS ..................3 PURPOSE OF THE DEVICE ......................... 4 SAFETY RULES ........................4 General safety instructions ....................4 Protection against electric shock ..................5 Safety instructions for working with the electric stapler ........5 MAINTENANCE AND REPAIR .......... -
Page 3: Warning / Information Symbols
WARNING / INFORMATION SYMBOLS ATTENTION: Before using the device, carefully read the instruction manual and safety recommendations. Keep the instructions. ATTENTION: Do not expose to rain and other precipitation. ATTENTION: Disconnect the device from the mains before carrying out maintenance and cleaning. -
Page 4: Purpose Of The Device
PURPOSE OF THE DEVICE The electric stapler is an electric tool with mechanical / spring action. With the help of nails and staples, it facilitates the work of joining elements. Correct, reliable and safe operation of the tool depends on proper operation, therefore: Read the entire manual before using the tool and keep it. -
Page 5: Protection Against Electric Shock
• The user is responsible for accidents or injuries to other people and for any damage to their property. • Always use the knife guard when transporting and storing the machine. Store the device in a dry place out of the reach of children. •... -
Page 6: Maintenance And Repair
jewelry as they may catch on moving parts of the device. Do not use the device if you are barefoot or wearing open sandals. • Maintain a stable posture while working, especially on steps and ladders. Avoid abnormal body posture. Always operate the machine with both hands. -
Page 7: A Description Of The Action
• Thoroughly clean the knife bar after each use. Wipe it with an oil-dampened cloth or spray it with a metal care spray. A DESCRIPTION OF THE ACTION Refilling the magazine 1. Squeeze the magazine clamps with your thumb and index finger. 2. -
Page 8: Troubleshooting
TROUBLESHOOTING Cause Solution Symptoms Check the socket, cable, mains and fuses, have them No mains voltage repaired if necessary electrician The device won't turn on Damaged on / off switch Repair by the service center. Worn carbon brushes Damaged engine Check cable, replace if Damaged power cord necessary. -
Page 9: Description Of The Device
DESCRIPTION OF THE DEVICE DESCRIPTION No | Mark No | Mark Power cable Button (trigger) ON / OFF switch A drawer for staples (nails) Outlet of staples / nails + stapler lock OPERATION OF THE ELECTRIC STAPLER Do not use the device without the hand guard. When working with this device, always wear safe work clothes and gloves. -
Page 10: Technical Data
This is indicated by the symbol on the product, manual or packaging. By reusing, reusing materials or other forms of using used devices, you make a significant contribution to the protection of our environment. MANUFACTURER'S DATA PH Powermat TMK Bijak Sp. Jawna Ul. Obrońców Poczty Gdańskiej 97 42-400 Zawiercie... -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY PART DIAGRAM Exploded view...
