Summary of Contents for Minolta CS-100A

  • Page 2 œ...
  • Page 3 Connection to personal computer ...... 1 <Caution related to connection> ......1 <Data output terminal> ........1 <Connection for RS-232C two-way communications> ....3 <Communication parameters> ........3 Setting to RS-232C mode ......4 <Setting procedure> .......... 4 Command list ......... 4 Notes on RS-232C mode ........
  • Page 4 INTRODUCTION This manual explains RS-232C two-way communications function of the chroma meter CS-100A. In case to use the data output function succeeded from the former model of CS-100, please refer to the instruction manual of CS-100A.
  • Page 5 œ Connect the connector to the proper direction securely. œ Always turn off the power of both this product and the personal computer before carrying out the connection. œ Remove the connection cord always holding the plug or the connector. And do not pull or forcibly bend the cord.
  • Page 6 Pin 1: Ground (GND) Pin 2: Ground (GND) ---- Pin 3: External equipment condition signal input. Use it OPEN (Busy in) Pin 4: RTS output Directly connects to the CTS terminal of the personal computer at the time of two-way communications by RS-232C. Outputted at the voltage level of about } 10V.
  • Page 7 This product side@@@@@@@@@@@@@@@@@ Personal computer side (1)or(2)pin œ\\\\\\\\\\\\\\\œ SG RTS output (4)pin œ\\\\\\\\\\\\\\\œ CTS CTS input (6)pin œ\\\\\\\\\\\\\\\œ RTS TxD output (7)pin œ\\\\\\\\\\\\\\\œ RxD RxD input (9)pin œ\\\\\\\\\\\\\\\œ TxD Set the parameters of the host computer following the RS-232C communication parameters of this product.
  • Page 8 1.Check the power is off. 2.Turn on the power switch with the F key of this product kept pressed. > 3.The letter of "C" is displayed in the right bottom corner of the external display. œ It is set to the RS-232C two-way communications mode. MES : Following the mode setting, measures one time Displays the measured value and outputs from the RS-232C terminal.
  • Page 9 In case to use in RS-232C two-way communications mode, it is recommended to carry out OPEN and CLOSE of RS port before or after transmitting one command. In case to use in RS-232C two-way communications mode, the consumption current increases comparing to the normal use. Especially if connected with the RS port of the personal computer side OPEN, electric current is consumed even if communication is not carried out, so pay attention.
  • Page 10 When the above-mentioned command (+ data) + delimiter is inputted from the control side, this product acts corresponding to the command and consecu- tively outputs the error check code (+ data) + delimiter. The delimiter is CR + LF and the break point of the data is a comma. The input and output is carried out with a format of fixed length determined for each command.
  • Page 11 " ¢¢ 12.4" (¢ is a space.). œ In"   " of the format of this product side (CS-100A) Ë the control side (personal computer), 0 - 9, and ".(period)", " (space)" comes in. The number of "   " means the number of letters. Therefore, in case to output the numeric value of "12.4"...
  • Page 12 Command Function œ@Following the mode setting, measures one time. œ@Outputs the measured value. Control side Ë this product format This product Ë control side format œ@When normal measurement "OK00, }       , }D     , }D     " œ@When luminance and chromaticity measuring range over (same as E0 display) "ER10"...
  • Page 13 Control sideËthis product format details In the 2-digit parameter following the command code, the following numeric value comes in according to the measuring mode to set. œ MINOLTA calibration standard mode "00" Same as the calibration switch [PRESET] side. œ@Arbitrary calibration standard mode "01"...
  • Page 14 This product Ë control side format œ@When normal measurement "OK00, }       , }D     , }D     " œ@When luminance and chromaticity measuring range over (same as E0 display) "ER10" œ@When chromaticity measuring range over (same as      E0 display) "OK11, }       , }D0000, }D0000" œ@When luminance display range over (same as E9 display) "OK12, | 999999, }D    ...
  • Page 15 Command Function Outputs the target value for measuring color difference memo- rized in the main body. Control side Ë this product format "TDR" This product Ë control side format "OK00,        ,D     ,D     " Control sideËthis product format details Command only This productËcontrol side format details œ@Following the error check command, outputs target luminance value Y, target chromaticity value x, target chromaticity value y.
  • Page 16 Command Function œ@Receives the target value for measuring color difference and memorizes in the main body. (On this product side, the fourth digit is rounded off because the display valid number of is 3-digit.) œ@The unit is recognized with the unit set on this product side. Control side Ë...
  • Page 17 Command Function œ@Receives the standard value for measuring user calibration standard and memorizes in the main body. œ@Calculate the coefficient for user calibration standard and memorizes. (On this product side, the fourth digit is rounded off because the display valid number of digit is 3-digit.) œ@The unit is recognized with the unit set on this product side.
  • Page 18 œ In the RS mode the color difference target data and the user calibration standard data can be inputted and outputted in valid numeral of 4 digits. œ In case to recall the set value memorized in the RS mode in the normal measuring mode, the fourth digit of the valid numeral is rounded off and displayed in 3 digits.
  • Page 19 œ This product has 4-digit data of valid number of digits for all Y, x, y inside and this 4-digit data are outputted. (As to Y, in numeric value of lower than 10, numeric value up to third decimal place is dealt.) œ...
  • Page 21 ¨ Being viewed from the CS-100A side, in case that the CTS becomes H, Set RTS to H if receiving is possible, and receives the data. In case that 1 packet is received, set RTS to L. In case that the edge of CTS enters during the command treatment, on the CS- 100A side, the receiving treatment starts when interrupt is still in during execution or after completing treatment.
  • Page 22 MINOLTA CO., LTD. Radiometric Instruments Operations Printed in Japan 2-3-13 Azuchi-cho, Chuo-ku, Osaka 541-8556, Japan...
