Features
• Maximum bass when there's little space
• Rugged, weather-resistant design
• Removable subwoofer grille
• Structurally rigid heavy duty voice coil
• Optimal thermal efficiency design
• Fiber matrix injection molded polypropylene cone
• Bass: The Final Frontier
Space™ Series
LOW-PROFILE SUBWOOFER
SPC-10S2 | SPC-10S4 | SPC-12S2 | SPC-12S4
User Guide
Advertisement
Related Manuals for AudioControl SPACE Series
Summary of Contents for AudioControl SPACE Series
- Page 1 Features • Maximum bass when there's little space • Rugged, weather-resistant design • Removable subwoofer grille • Structurally rigid heavy duty voice coil • Optimal thermal efficiency design • Fiber matrix injection molded polypropylene cone • Bass: The Final Frontier Space™...
-
Page 2: Important Safety Instructions
Use speaker wire of sufficient size to ensure adequate current to the speak- er. For Space Series Subwoofers, this means 10-14 gauge speaker wire. To prevent excessive cone excursion and potential damage to the sub- woofer is it advisable to use a infrasonic (subsonic) filter set 1/2 octave below Fb. - Page 3 If you're not into math, or have trouble for each subwoofer size in the following pages. Whether buying pre-made plugging in power tools, your best bet is to seek out a qualified AudioControl or designing and building a custom enclosure, try to stay within these dealer.
-
Page 4: Ported Enclosure
Space™ Series SPC-10S2 Specifications Thiele/Small Parameters Dimensions Nominal Impedance (Z) ..............2 ohms Overall Diameter (A) ............10.39 in/264 mm DC Resistance (Re) ................1.8 ohms Cut Out Diameter (B) ............9.13 in/232 mm )............Mounting Depth (C 3.50 in/89 mm Resonance Frequency (Fs) ...............37.48 Hz )........ - Page 5 SPC-10S4 Specifications Thiele/Small Parameters Dimensions Nominal Impedance (Z) ..............4 ohms Overall Diameter (A) ............10.39 in/264 mm DC Resistance (Re) ................3.2 ohms Cut Out Diameter (B) ............9.13 in/232 mm )............Resonance Frequency (Fs) ............37.3460 Hz Mounting Depth (C 3.50 in/89 mm )........
- Page 6 Space™ Series Enclosure Example SPC-10S2/10S4 Ported Enclosure 24.00” 12.00” Specifications External Dimensions ..24.00" W × 14.50"H × 12.00"D 21.50” 10.50” Net Internal Volume ............1.40 ft3 Total Internal Volume............1.75 ft3 Gross External Volume ............2.38 ft3 Material Thickness ..............0.75" Tuning Frequency ..............40 Hz Port Area ...............22.75 inch2 Port Inlet ............1.75"W×...
- Page 7 Enclosure Example SPC-10S2/10S4 Sealed Enclosure Specifications 26.00” 3.50” External Dimensions ....26.00" W × 14.50"H × 5.00"D Net Internal Volume ............0.60 ft3 Total Internal Volume............0.65 ft3 Gross External Volume ............1.09 ft3 Material Thickness ..............0.75" F3 (Hz) ....................60 Qtc ....................0.703 Material Prep Front / Rear 26.00"...
- Page 8 Space™ Series SPC-12S2 Specifications Thiele/Small Parameters Dimensions Nominal Impedance (Z) ..............2 ohms Overall Diameter (A) ............12.37 in/316 mm DC Resistance (Re) ................1.8 ohms Cut Out Diameter (B) ............11.10 in/282 mm )............Mounting Depth (C 3.94 in/100 mm Resonance Frequency (Fs) ............27.8430 Hz )........
- Page 9 SPC-12S4 Specifications Thiele/Small Parameters Dimensions Nominal Impedance (Z) ..............4 ohms Overall Diameter (A) ............12.37 in/316 mm DC Resistance (Re) ................3.2 ohms Cut Out Diameter (B) ............11.10 in/282 mm )............Resonance Frequency (Fs) ............30.7061 Hz Mounting Depth (C 3.94 in/100 mm )........
- Page 10 Space™ Series Enclosure Example SPC-12S2/12S4 Ported Enclosure 24.00” 15.00” Specifications External Dimensions ..24.00" W × 15.00"H × 15.00"D 21.25” 13.50” Net Internal Volume ............2.02 ft3 Total Internal Volume............2.28 ft3 Gross External Volume ............3.01 ft3 Material Thickness ..............0.75" Tuning Frequency ..............40 Hz Port Area ...............27.00 inch2 Port Inlet ............2.00"W×...
- Page 11 Enclosure Example SPC-12S2/12S4 Sealed Enclosure Specifications 32.00” 5.50” External Dimensions ....32.00" W × 15.00"H × 7.00"D Net Internal Volume ............1.25 ft3 Total Internal Volume............1.31 ft3 Gross External Volume ............1.94 ft3 Material Thickness ..............0.75" F3 (Hz) ....................51 Qtc ....................0.765 Material Prep Front / Rear 32.00"...
- Page 12 Months of waiting around. Well, fear no more. This warranty is designed to two (2) years. make you rave about AudioControl. It’s a warranty that looks out for you and 4. Our warranty covers AudioControl products that have been installed your client, plus helps you resist the temptation to have your friend Sparky, according to the instructions in this manual.
- Page 13 Promises of how well your AudioControl product will work are not implied by this warranty. Other than what we’ve said we’ll do in this warranty, we have no obligation, express or implied.
- Page 14 Complimentary Layout Page Space™ Series (tape measure and calculator not included) User Guide...
- Page 15 Mountlake Terrace, WA 98043 USA Phone: 425-775-8461 email: sound.great@audiocontrol.com ©2023 AudioControl. All rights reserved. As technology advances, AudioControl reserves the right to continuously change our specifications, like our Pacific Northwest weather, although we are working on changing that as well.
- Page 16 Space™ Series The End ( Thanks for hang'n in there) User Guide PN 913-177-0 Rev D...
