Gas Type Conversion NG/LPG
1.1 TYPES OF CONVERSIONS
1.1.1 EG SERIES ELECTRONIC
NG to LPG
1.
Jets needs to be replaced.
2.
Jumper needs to be removed from the control box.
3.
Pressures needs to be adjusted.
4.
Pilot needs to replaced, make sure air-intake is opened.
LPG to NG
1.
Jets needs to be drilled out
2.
Jumper needs to be added to the control box.
3.
Pressures needs to be adjusted.
4.
Pilot needs to replaced, make sure air-intake is closed.
1.1.2 SG SERIES MANUAL
NG to LPG
1.
Jets needs to be replaced.
2.
Remove NG regulator
3.
Pressures needs to be adjusted.
4.
Pilot needs to be adjusted and air-intake on it opened.
LPG to NG
1.
Jets needs to be drilled out
2.
NG regulator to be added
3.
Pressures needs to be adjusted.
4.
Pilot needs to be adjusted and air-intake closed
1
Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
16 March 2023
Advertisement
Table of Contents
Related Manuals for Warmington EG Series
Summary of Contents for Warmington EG Series
- Page 1 Jets needs to be drilled out NG regulator to be added Pressures needs to be adjusted. Pilot needs to be adjusted and air-intake closed Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
- Page 2 To access the jets the burner tray needs to be taken off. To do this undo the 2x bolts on top of the burner legs on each side, and 1x bolt for the pilot assembly. Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
- Page 3 For LPG to NG the jet head can be drilled out. To get the appropriate jet size please refer to the table in section 1.2. The drill bit has to be accurate to the correct decimal, and can be supplied by Warmington. Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
- Page 4 When you are satisfied that the Appliance is working correctly , fit the Front Panel Assembly back to the Gas • Burner. All Burner Aerations are Factory Preset and cannot be adjusted. • Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
- Page 5 When you are satisfied that the Appliance is working correctly, fit the Front Panel Assembly back to the Gas • Burner. All Burner Aerations are Factory Preset and cannot be adjusted. • Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
- Page 6 NG, please match this as shown below. Fully open air- intake, hence this Half open air- is a LPG unit intake, hence this is a NG unit Due to continued product improvement, Warmington Ind LTD reserves the right to change product specifications without prior notification.
- Page 7 NG to LPG this needs to be removed. If the fire is converted from LPG to NG this needs to be installed. Regulator will be supplied by Warmington and removal or installation of one has to be done by a certified gas fitters, as the plumbing of the gas fire will have to be changed.
