Summary of Contents for UniFlow microMIND V2
- Page 1 V2 Installation & Configuration Manual...
- Page 3 V2 - Installation & Configuration Manual - V2.5.pdf Technologies ▪ microMIND V2 ▪ Concerned ▪ microMIND V2 POE ▪ This manual describes the features, the installation, and the configuration of the microMIND V2 in detail. Short Summary microMIND® is a registered trademark of NT-ware Systemprogrammierungs-GmbH.
- Page 4 Document Version Chapter Changes Changes Added information about the DNS name of the microMIND V2. Added Firmware update chapter and improved Firmware update (on page 14) several formatting issues. Technical Specifications (see Specifications Added CE, FCC, VCCI, C-Tick and UL marks.
- Page 5 NT-ware trademarks uniFLOW®, mdsFLOW®, uniFLOW Serverless Secure Printing®, Helix Production Workflow®, MIND®, microMIND®, and MiCard® are registered trademarks of NT-ware Systemprogrammierungs-GmbH. Third-party trademarks Adlib, Express, and Express Server are either registered trademarks or trademarks of Adlib Publishing Systems Inc.
- Page 6 SQL databases. We strongly suggest that you refrain from modifying these SQL databases manually without prior consultation from the NT-ware support team. NT-ware does not assume responsibility or liability for possible impact on your uniFLOW environment after modifying any of the SQL databases. Copyright and Contact NT-ware Systemprogrammierungs-GmbH Niedersachsenstraße 6...
- Page 7 Feedback Should you come across any relevant errors or have any suggestions, please contact documentation@nt- ware.com or use the Send feedback button of the uniFLOW Online Help. Technical Support Your dealer will provide the first technical support services. Before contacting your dealer for technical...
-
Page 8: Legal And Safety Notices
Legal and Safety Notices Intended Use of NT-ware Products NT-ware products may only be used for the applications specified in this manual and the associated technical documentation. If third-party products and components are used, they must be recommended or approved by NT-ware. Use NT-ware products only with accessories approved by us. Correct and safe operation of the products requires proper transport, storage, installation, assembly, commissioning, operation, and maintenance. - Page 9 Pictograms Important Note: Information that is crucial for the correct functioning of the software. Further Information: Pointer to additional manuals, installation manuals, white papers or the NT-ware Knowledgebase. Region Specific Feature: Indicator for features that are not available worldwide. External Link: Link to an external web page.
-
Page 11: Table Of Contents
6 microMIND V2 Website........ - Page 12 Contents 9 Specifications..........20 Compliance and Disposal Notes.
-
Page 13: Introduction
Introduction Introduction The microMIND V2 allows to add a MiCard reader or a MiCard PLUS / MiCard PLUS-2 / MiCard PLUS-2 V2 reader as a secure print solution to any printer. This allows you to turn your normal office printer into a cost-effective secure print solution. It does not matter whether this printer is connected via USB, the network, or a different connection. - Page 14 Introduction microMIND V2 (secure printing and copy accounting / device locking)
-
Page 15: Scope Of Supply
The microMIND V2 package includes: ▪ The microMIND V2 device. ▪ ▪ A patch cable to connect the device to a printer. ▪ ▪ Power supply (if no PoE microMIND V2). ▪ ▪ The microMIND V2 Installation Guide. ▪ ▪ Hook-and-loop fastener. -
Page 16: Installation
6. Attach the microMIND V2 to the network. 7. Plug-in the power supply of the microMIND V2 if required. This is necessary if you have no PoE microMIND V2 or if you have a PoE microMIND V2, but your network does not support PoE. -
Page 17: Led Status
LED Status LED Status The microMIND V2 is equipped with two status LEDs. The tables below show the status information given by the respective LED. Power LED: Status/Colors Status Descriptions No power supplied or boot loader phase (see also chapter Firmware Update). - Page 18 LED Status Status/Colors Status Descriptions Green A link to a network is established. Green flashing A link to a network is established and data is transmitting. Yellow ON The network speed is 100 Mbit/s. Yellow OFF The network speed is 10 Mbit/s.
-
Page 19: Configuration
3. The microMIND V2 IP configuration can be found by selecting a microMIND V2 via mouse click on the IP address. You’ll find the serial number of the respective microMIND V2 on a sticker on the back of the microMIND V2. A browser screen will open to configure the microMIND V2 IP address. -
Page 20: Code Conversion
Code Conversion for microMIND. However, the Code Conversion can be set to a "Global Code Conversion" for all ID devices or to microMINDs only. The configuration is done on the in uniFLOW Server Configuration > Server Config. > General Settings > General > Code Conversion. - Page 21 Configuration ◦ StringReverse ◦ ◦ ReverseHexBytes ◦ ◦ ReverseBitorderInBytes ◦ ◦ ConvertToAscii ◦ ◦ RemoveFirst <n> ◦ ◦ RemoveLast <n> ◦ ◦ RestrictLength <n> ◦ ◦ CodeLength <n> ◦ where <n> represents a numeric parameter. You can enter one command per line. A '#' can be used for comments. ▪...
-
Page 22: Micromind V2 Website
▪ Serial Number: ▪ This is the serial number of the microMIND V2 itself. It is used to select a microMIND V2 during a printer configuration. You will also find this number on a sticker on the back of each microMIND V2. The serial number is displayed in hexadecimal format and reflects the last 3 Bytes of the device's MAC address. -
Page 23: Usb Device
V2. The uniFLOW Server will always have access to the microMIND V2 independent of the settings here. If left blank, there is no access limitation. HTTP port 80 must not be blocked by a firewall to reach the microMIND V2 website. USB Device The USB Device site gives information about the following: ▪... -
Page 24: Port Configuration
▪ MiCard V2 HID: use extended data: ▪ By default this parameter is disabled. You only need to enable this option, if you have upgraded an SSP (Serverless Secure Printing) installation to uniFLOW. ▪ Upload USB HID configuration file: ▪... -
Page 25: About
V2 Website About The About site shows legal information. - Page 26 V2 Website...
-
Page 27: Firmware Update
1. Format your USB stick according to the requirements listed above. 2. Copy the MMAPP file onto the USB stick. 3. Detach your microMIND V2 from the power supply. If PoE is used, detach the network connection. 4. Attach the USB stick to the microMIND V2. -
Page 28: Firmware Update Via Uniflow
Manual firmware update via uniFLOW In case you have uploaded a new microMIND V2 firmware only and decided to update dedicated microMIND's V2 manually, do the following: 1. Choose the firmware from the drop-down list. -
Page 29: Micromind V2 Signal Interpreter And Configuration
V2 Signal Interpreter and Configuration microMIND V2 Signal Interpreter and Configuration The microMIND V2 signal interpreter allows the configuration of simple pattern matching rules. These include multi-click and clock driven events while observing multiple I/O port pins in parallel. -
Page 30: Canon Signal Kit A1/A2
V2 Signal Interpreter and Configuration ▪ {number}: 1,2,3,... up to 16. Do not use a leading 0, i.e. do not use RULE01, RULE02 … ▪ but instead RULE1, RULE2 … ▪ {product}: product index which is used for click counting if the rule matches. The ▪... - Page 31 V2 Signal Interpreter and Configuration REVERSE=0 INVERT=0 [DIPORT0] DEBOUNCE=0 EDGE=0 TIMEOUT=0 RULE1=1,b1110,b0110,-1,0 #Copy A3 Color RULE2=2,b1110,b0010,-1,0 #Copy A3 RULE3=3,b1110,b0100,-1,0 #Copy A4 Color RULE4=4,b1110,b0000,-1,0 #Copy A4 RULE5=5,b1110,b1110,-1,0 #Print A3 Color RULE6=6,b1110,b1010,-1,0 #Print A3 RULE7=7,b1110,b1100,-1,0 #Print A4 Color RULE8=8,b1110,b1000,-1,0 #Print A4...
-
Page 32: Specifications
The two different versions can easily be distinguished by the sticker on the back. If you have a microMIND V2 that does not support PoE or if your network switch does not support PoE, you have to use the respective power supply. - Page 33 Never use alcohol, benzene, paint thinner, aerosol sprays, or any other highly flammable substance for cleaning. Modifications Changes and/or modifications of the microMIND V2 not approved by NT-ware will invalidate the user's authority to operate the microMIND V2. microMIND V2 to Canon Signal Kit A1/A2 Connection...
- Page 34 Specifications microMIND V2 IO-Connector...
-
Page 35: Compliance And Disposal Notes
Specifications Compliance and Disposal Notes FCC Compliance Notes (for USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 36 Specifications The correct disposal of this product will help save valuable resources and prevent any potential negative effects on human health and the environment, which could otherwise arise from inappropriate waste handling. Please contact your local authority for further details of your nearest designated collection point.
-
Page 37: Eu Declaration Of Conformity
Specifications EU Declaration of Conformity NT-ware hereby declares that the radio equipment type microMIND V2 complies with the Directive 2014/53/EU. The full text of the EU Declaration of Conformity can be found under the following URL: http://link.nt-ware.net/id160 China RoHS 产品说明书附件... - Page 38 Specifications 此标志也表示了该产品及其部件的环保使用期限。当某些零部件有不同的环保使用期限 时，会另行标示(例如,电池单元模块会有另外一个标志贴在其产品上）。 此环保使用期限只适用于产品是在产品手册中所规定的条件下工作。 The Environment- Friendly Use Period (EFUP) for all enclosed products and their parts are per the symbol shown here, unless otherwise marked. Certain parts may have a different EFUP (for example, battery modules) and so are marked to reflect such. The Environment- Friendly Use Period is valid only when the product is operated under the conditions defined in the product manual.
-
Page 39: Faq
The MAC Address consists of two parts. The first part is the vendor ID for NT-ware, which is always the same: 743256 The second part is the serial number of the microMIND V2, for example 100012. Following this, the resulting MAC Address will be: 74:32:56:10:00:12 How can I reset the port configuration settings to its default values? Open the microMIND V2 website and select the Port Configuration page. - Page 40 i. New user name: Enter the new user name. ii. Repeat user name: Repeat the entered user name. iii. New Password: iii. Enter a new password. iv. Repeat password: Repeat the entered password. The new user name and the new password are successfully stored. ...
- Page 41 ......... . 16 microMIND V2 Website..... . . 9...
- Page 42 © NT-ware 2009-2022...
