- Page 1 BeaverLAB Intelligent Microscope MX DDL MX Instruction Manual Please read this user manual carefully! Better reading experience! Please keep the manual properly!
-
Page 2: Table Of Contents
Catalogue 1. Product Overview 2. Instructions For Use 3. Instructions For Using Microscope 4. Instructions For Operate Steps of the microscope 5. User Guide For Interface 6. Function Description Of External Equipment 7. Accessories And Tools 8. Troubleshooting Of Microscope 9. -
Page 3: Product Overview
1 Product Overview ∙ Thank you for purchasing BeaverLAB intelligent microscope, hereinafter referred to as microscope. ∙ Please read this manual carefully and keep it properly before use. Do not use the microscope without any instructions. -
Page 4: Instructions For Use
2 Instructions For Use Please read this manual carefully and use it correctly. Pay attention to protect the lens. Be sure to close the lens cover after using, avoid entering dust or foreign matters. Pay attention to protect the display screen. Please close the screen after using, avoid damaging the display screen. -
Page 5: Instructions For Using Microscope
3 Instructions For Microscope Microscope Composition Screen Host Head Upright column Objective Lense Lifting Table Base... - Page 6 Knob Function Description Objective Lens Lighting Adjusting Knob Turn it on clockwise & increase the brightness Turn the brightness down Platform Bottom Light Adjustment Knob Turn it on clockwise, turn it up, turn it down Focusing Knob (Fine Adjustment) Zoom out clockwise / zoom in counterclockwise Objective Lens Switching Knob 100x / 600X / 1200X switch by rotation...
- Page 7 Interface Usage Long press on / It can be operated by connecting the mouse Charging / Data Transmission Port DC5V Charging / Using Adapter You can connect your mobile phone to export data Connect windows computer and operate with computer software Use Environment Please use it at- Please prevent the...
- Page 8 Charging Instructions The red light is always on during charging and the green light is always on after charging Can use daily mobile phone Do not charge for more than charger, computer The power bank charges the microscope. service life of the battery. During charging, if the microscope shell and battery have slight heating, it is normal.
- Page 9 4 Instructions for using the microscope 1. Place Stably 2. Open the screen 4. Move the platform to a suitable long time to start the machine...
- Page 10 5. Remove the lens cover and put in the observation items 6. Select the multiple to be observed (note (note that the specimen should be facing the eyepiece) that the specimen should be facing the eyepiece) 7. Raise the platform to a suitable height 8.
- Page 11 9. Focus through the focusing knob and observe 10. The observation position can be moved by the display screen to a clear position adjusting the moving knob under the platform The Pithy Formula For Microscope Use: large multiples should be close and small multiples should be far Use Of Specimen Holder Specimen Fixing Clip Fixed specimen or observation target...
- Page 12 Matters Needing Attention: the base. adsorption of other metal substances. Use Of Observation Panel Observation Center Indicator Arrow Matters Needing Attention: The observation panel shall be wiped regularly to avoid oil stain or other stains affecting the observation experience. Description of light adjustment function of observation window pay attention to the adjustment and use.
- Page 13 5. Interface User Guide Software interface function introduction： Straight Line Circular Casual Painting Gallery Angle Take A Picture Rectangle With Record Video Rounded Ellipse Dimensional calibration Measure the internal Delete dimensions of the Undo / Return calibration system Connect to the computer through settings switching...
- Page 14 Dimensional calibration Set Up Shut Down Measure the internal dimensions Language: Chinese / English of the calibration system Time :time/ date Sleep: never / 3 min / 5 min / 10 min / 15 min Timed Shutdown: never / 5 min/ 10 min / 30 min / 1 hour Memory Card Switching: in / out Camera Switching: in / out...
-
Page 15: Function Description Of External Equipment
6 Function Description Of External Equipment 一、Connect To Mobile Phone Purpose: Read the pictures in the microscope memory with the mobile phone or copy them to the mobile phone. Operation method: ① Plug the data cable into the DC5V charging port of MX microscope, plug the adapter into the mobile phone end, and connect the data cable with the adapter. - Page 16 ① Plug the data cable into the DC5V charging port of MX microscope, and connect one end to the USB interface of computer. ② Open BeaverLAB computer software (only windows computers are supported). ③ Open the MX microscope and click: Setting →...
- Page 17 Click Connect Device Click Select Device ④ In the computer software, click: connect device button → select device (select the Click Confirm recognized camera device) → open ⑤ At this time, the software on the computer side is directly connected to the camera, so you can use the computer to observe directly.
-
Page 18: Accessories And Tools
7 Accessories And Tools Magnetic specimen holder x2 Adapter Data Line Prepared Slides x10 8 Troubleshooting Of Microscope Problem Phenomenon Reason Processing Method During charging, the current is large and the calorific value of the battery is Lifting is not smooth / Normal state Unable to lift high, which is a normal... - Page 19 9 Trademark And Legal Declaration ”、“ “ BeaverLAB " is a trademark applied for or registered in Chinese Mainland by Beaver Technology Co., Ltd. and is used on this product use. Without the permission of thetrademark owner, no person or institution may use the above trademark logo on unapproved goods without authorization.
- Page 20 ② Within 8-15 days from the next day after you sign for it, if this product has any performance failure listed in the performance failure table of BeaverLAB intelligent microscope products, it can enjoy the replacement or maintenance service free of charge after being tested and determined by BeaverLAB after-sales service center;...
- Page 21 ② The warranty period has expired; ③ Damage caused by force majeure; ④ It does not comply with the performance faults listed in the performance fault table of BeaverLAB intelligent microscope products; ⑤ Due to human factors, this product and its accessories have the performance faults listed in the performance fault table of BeaverLAB intelligent microscope products.
- Page 22 Intelligent Microscope MX Product Name: Intelligent microscope MX Input Voltage: DC5V Brand Name: BeaverLAB Executive Standard： CE FCC Product Model: DDL-MX Battery Capacity: 3500mAh Product Size: 214x224x324mm Display Size: 9 inches Brand Company: Beaver Technology (Shenzhen) Co., Ltd. Service Mailbox: support@beaverlabtech.com...
