DAUDIN iO-GridM GFGW-RM02N User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2211TW
V3.0.0
iO-GRID M
Gateway Module User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iO-GridM GFGW-RM02N and is the answer not in the manual?

Questions and answers

Related Manuals for DAUDIN iO-GridM GFGW-RM02N

Summary of Contents for DAUDIN iO-GridM GFGW-RM02N

  • Page 1 2211TW V3.0.0 iO-GRID M Gateway Module User Manual...

  • Page 2: Table Of Contents

    Table of Contents Gateway Module List ...................... 3 Product Description ......................3 Gateway Module Specification ..................5 GFGW-RM01N ....................5 GFGW-RM02N ....................6 Gateway Module Information ................... 7 Gateway Module Dimensions ................7 Gateway Module Panel Information ............... 8 Module Installation/Disassembly ..................11 Installation ......................

  • Page 3: Gateway Module List

    1. Gateway Module List Default IP Product No. Description address GFGW-RM01N Modbus TCP-to-Modbus RTU/ASCII gateway module, 4 Ports 192.168.1.20 GFGW-RM02N Modbus TCP-to-Modbus RTU/ASCII gateway module, 1 Port 192.168.1.20 Product Description GFGW, Modbus Gateway series is designed for industrial applications. It is an open industrial device for installation in a housing provided on site.
  • Page 4 Caution (ATTENTION) THIS DEVICE IS FOR INDOOR USE ONLY, DON’T PUT OR USE IT IN HIGH TEMPERATURE AND HIGH MOISTURE ENVIRONMENT. CET EQUIPEMENT EST DESTINE A UN USAGE INTERIEUR UNIQUEMENT NE PAS STOCKER OU UTILISER DANS UN ENVIRONNEMENT A HAUTE TEMPERATURE ET HAUTE HUMIDITE. AVOID FALLING AND BUMPING OTHERWISE THE ELECTRICAL COMPONENTS WILL BE DAMAGED.

  • Page 5: Gateway Module Specification

    2. Gateway Module Specification 2.1 GFGW-RM01N Technical Specification Module Type Modbus TCP Gateway Voltage Supply 5 VDC via Dinkle Bus Current Consumption 400 mA @ 5 V Number Of Communication Ports Ethernet * 2 / RS485 * 4 Network Interface RJ45 * 2 Serial Communication Interface RS485 (push-in contact)

  • Page 6: Gfgw-Rm02N

    2.2 GFGW-RM02N Technical Specification Module Type Modbus TCP Gateway Voltage Supply 5 VDC via Dinkle Bus Current Consumption 400 mA @ 5 V Number Of Communication Ports Ethernet * 2 / RS485 * 1 Network Interface RJ45 * 2 Serial Communication Interface RS485 via Dinkle Bus Communication Protocol Modbus TCP / RTU...

  • Page 7: Gateway Module Information

    3. Gateway Module Information 3.1 Gateway Module Dimensions I. GFGW-RM01N Unit: mm II. GWGW-RM02N Unit: mm...

  • Page 8: Gateway Module Panel Information

    3.2 Gateway Module Panel Information I. GFGW-RM01N LED indicator Ethernet reset Ethernet port 1 button 10/100Mbps RJ45 port Ethernet port 2 10/100Mbps RJ45 port RS485 2-wire port R485 RS485 2-wire port communication RS485 2-wire port indicators RS485 2-wire port LED indicator definition Color Definition Status...
  • Page 9 RS485 port definitions RS485 Communication pin definitions Serial port A of the first RS485 Serial port B of the first RS485 Serial port A of the second RS485 Serial port B of the second RS485 Serial port A of the third RS485 Serial port B of the third RS485 Serial port A of the fourth RS485 Serial port B of the fourth RS485...
  • Page 10 II. GFGW-RM02N LED indicator Ethernet reset Ethernet port 1 button 10/100Mbps RJ45 port Ethernet port 2 10/100Mbps RJ45 port RS485 communication indicator LED indicator definition Color Definition Status On: Power on Green power indicator Off: Power off Blinking: System running Green Run Indicator Off: Power off...

  • Page 11: Module Installation/Disassembly

    4. Module Installation/Disassembly 4.1 Installation I. Align the red arrow on the side of the module to the arrow on the DIN rail. II. Press the module down and the metal clamp will slide (thanks to its spring mechanism) and grab on the other side of the DIN rail. Continue to push down until the metal clamp “clicks”.

  • Page 12: Removal

    4.2 Removal I. Use a screwdriver to pull the metal hook sideways and detach the module from the DIN rail. II. Remove all modules from the DIN rail in reverse order of installation.

  • Page 13: Io-Grid M Series Introduction

    5. iO-GRID M Series Introduction iO-GRID M series utilizes the standard Modbus communication protocol and supports Modbus RTU/ASCII and Modbus TCP. Please choose products and factory controllers to figure your system based on your communication protocol. 5.1 iO-GRID M Components I.
  • Page 14 II. Gateway Module A gateway module converts between Modbus TCP and Modbus RTU/ASCII. The module provides two sets of external Ethernet ports to connect to the controller and the Internet There are two types of gateway modules available: 4-channel gateway module: Provides 4 RS485 ports to connect to a control module Single-channel gateway module: No external connectivity for the RS485 ports.
  • Page 15 IV. I/O Module Dinkle offers different types of I/O modules with different functions: Product No. Description GFDI-RM01N 16-channel digital input module (source/sink) GFDO-RM01N 16-channel digital output module (sink) GFDO-RM02N 16-channel digital output module (Source) GFAR-RM10 8-Channel relay module, grounded GFAR-RM20 4-Channel relay module, grounded GFAI-RM10 4-channel analog input module (±10VDC)

  • Page 16: I-Designer Parameter Settings And Information

    6. i-Designer Parameter Settings and Information 6.1 Gateway Module Connection Setup Gateway Module System Configuration List Name/Product No. Description GFGW-RM01N Modbus TCP-to-Modbus RTU/ASCII gateway module. 4 Ports GFGW-RM02N Modbus TCP-to-Modbus RTU/ASCII gateway module. 1 Port Computer Only needs to support Ethernet RJ45 port connections II.
  • Page 17 IV. Gateway Module Connection Setup Connect your gateway module to your computer via the Internet port and then open i-Designer the i-Designer program to set up gateway module parameters Gateway module connection illustration: Gateway module connection image:...

  • Page 18: I-Designer Gateway Module Setup Process

    6.2 i-Designer Gateway Module Setup Process Preliminary operation 1 After connecting the gateway module to your computer, open “Control Panel” -> “All Control Panel Items” -> “Network and Sharing Center” and then click on “Change adapter settings” 2 Click on the Ethernet icon -> “Properties” and then click on “TCP/IPv4) 3 Confirm that the network setting is the same as the gateway module setting...
  • Page 19 of “192.168.1.XXX”...
  • Page 20 V. Make sure that the module is powered and connected to the gateway module using an Ethernet cable VI. Click to launch the software...
  • Page 21 VII. Select “M Series Module Configuration” VIII. Click on the “Setting Module” icon...
  • Page 22 IX. Enter the “Setting Module” page for M-series X. Select the mode type based on the connected module...
  • Page 23 XI. Click on “Connect” XII. Gateway Module IP Settings Network setting parameters include: IP address, subnet mask, default gateway and MAC address (non-changeable) 1) Set up the IP address. 2) Set up the subnet mask. 3) Set up the default gateway. 4) Click on “Setup”...
  • Page 24 XIII. Communication formats of the 4 RS485 on the gateway module Serial port parameters of each serial port's RS485 (including baud rate, Modbus communication format and parity checking and stop bit. Set up the baud rate transmission speed at each serial port Set up the Modbus communication format (RTU/ASCII) at each serial port.
  • Page 25 XIV. Gateway Module Operational Modes The operating mode parameters include: Choosing the master/slave modules for the each RS485 serial port and slave modules’ communication timeout settings. Choose each serial port’s master and slave. Choose “master” for the serial ports connecting the controller and “slave” for the other serial ports (Simply put, when TCP>RTU, choose slave;...
  • Page 26 XV. Gateway Module ID mapping ID mapping parameters include: mapping IP of the master module in the operation mode and the mapping ID range for the slave module. In the “master” module’s operation mode, set up the corresponding master’s IP address.

  • Page 27: Gfgw-Rm01N Button Reset

    GFGW-RM01N Button Reset Reset button location Reset button location II. Reset button function Press and hold for 1 to 3 seconds Reset IP address Press and hold for more than 3 seconds Reset IP address and module settings III. Press and hold for 1 to 3 seconds to reset the IP address If the IP address is forgotten, press the reset button to reset the module’s IP address to default setting (Gateway module's default IP address is 192.168.1.20)
  • Page 28 IV. Press and hold for more than 3 seconds to reset operating mode, network settings, serial port setting and ID mapping. The image below is the module default settings...
