- Page 1 MTD MULTICLAMP Operator’s Manual www.isco-pipe.com | 800-345-4726...
- Page 2 This manual is not intended to be used for system design purposes and does not take the place of the advice of a professional engineer. Should any issue or difficulty arise while operating this equipment, contact ISCO Industries, Inc. MTD MultiClamp Operator’s Manual...
- Page 3 MultiClamp system. Under no circumstances should the factory recommended specifications be exceeded. If the operator or other personnel have questions regarding the operation of this system, please contact ISCO. Always refer to and follow your company’s safety procedures. Protective Clothing Gloves, flame retardant shirt, safety glasses, safety shoes, and hard hat are recommended.
-
Page 4: Component List
COMPONENT LIST Multi-Clamp assembly (x2) Hex Tool V Clamp (x4) Multi-Angle Connector Nylon Straps (x4) Sliding V-Clamp Base (x4) - Page 5 PROCEDURES Step 1: Configuring the MTD MultiClamp Before setting up the MTD MultiClamp, determine what type of fitting you will be clamping, and configure the clamping assemblies accordingly. Note: Multi-Angle Connector is not required for some couplings. One of the clamping assemblies may be used as a bar-style clamp with two V-Clamps.
- Page 6 Step 2: Installing Sliding V-Clamp Base In order to install the V-Clamps on the MTD MultiClamp assembly, first install the sliding V-Clamp bases. There are four bases provided, one for each V-Clamp. To install a V-Clamp base, place the bottom half of the base beneath the assembly and push up through the slot, as pictured below.
- Page 7 Step 3: Installing and Adjusting V-Clamps Before placing fitting assembly into clamping assembly, determine the distance you will require for the V-Clamps to sit under the pipe and adjust the position of the bases accordingly. Note: Some fittings will require removal of one of the two V-Clamps from each sliding base.
- Page 8 Adjusting V-Clamps according to fitting After adjusting the V-Clamps to desired positions, securely tighten them to the sliding V-Clamp base using the included hex tool so that there is no movement of the V-Clamp on the sliding base. Assembled Multi-Clamp...
- Page 9 Note: Some fittings may require support blocks. If this is necessary, wooden blocks may be used as support blocks. Step 5: Secure fitting assembly to MTD MultiClamp After fitting assembly is properly situated in Multi-Clamp, install nylon straps on V-Clamps by passing one end of strap through ratchet mechanism slot and hooking the other end around the desired rung on the opposite side of the V-Clamp.
- Page 10 After installing straps, tighten ratchet mechanisms on each V-Clamp to secure pipe and fitting to the clamp. Placing hook end around rung on V-Brace Step 6: Fuse fitting assembly After tightening all straps, ensure that the fitting assembly cannot move in the clamp.
- Page 11 If fusing a three-way tee, put Multi-Clamp in straightened position first and fuse the two ends as pictured below. Once the two ends have been fused, unstrap the pipe, remove it from the Multi-Clamp, and change the clamp to the 90° position. Reinstall the pipe on the Multi-Clamp, along with the coupling and third piece of pipe to be fused.
- Page 12 | 800-345-4726 © Copyright 2022, All Rights Reserved, ISCO Industries, Inc.
