- Page 1 MTD POLYPEEL Operator’s Manual www.isco-pipe.com | 800-345-4726...
- Page 2 This manual is not intended to be used for system design purposes and does not take the place of the advice of a professional engineer. Should any issue or difficulty arise while operating this equipment, contact ISCO Industries, Inc. MTD PolyPeel Operator’s Manual...
- Page 3 PEELER PART NUMBER Part Number Size TRI1960 1/2” CTS TRI196065 1/2” CTS (0.090 wall) TRI1963 1/2” IPS TRI1965 3/4” IPS TRI19656 3/4” (SDR11 only) TRI19690 3/4” CTS (0.090 wall) TRI1970 1” CTS TRI19704 1” CTS (0.090 wall) TRI19706 1” CTS (0.099/0.101 wall) TRI19707 1”...
-
Page 4: Field Application
When utilizing this tool with coiled pipe, ensure that pipe has less than 10% ovality. FIELD APPLICATION Step 1 Mark the stab depth of the fitting prior to inserting MTD PolyPeel into pipe as directed in picture. - Page 5 Step 2 Press down on thumb grip and lock arm open by placing arm retainer pin into slot in thumb grip. Step 3 Secure mandrel into outlet of tapping tee/pipe to be scraped by rotating in a clockwise motion via knurled grip on mandrel.
- Page 6 Step 4 Once mandrel is secure, rotate MTD PolyPeel body counter-clockwise to position blade directly over end of outlet/pipe to be scraped. Unlock blade arm by pressing down on the thumb grip and setting retaining pin into cutout. Allow blade to rest on surface of outlet/pipe.
- Page 7 Peeling is complete when stab depth marking is removed as shown in picture above. Step 6 After peeling is complete, press down on thumb grip and unlock arm as in Step 2. Remove mandrel from outlet/pipe by rotating mandrel counter-clockwise, opposite of Step 3.
- Page 8 Then remove the blade and rotate it to the opposing side, re-install the blade and machine screw into the blade arm. Test the peeler to ensure proper removal of pipe material. Once all four faces of the blade have been worn, contact ISCO for a replacement blade.
- Page 9 TOOL DIAGRAM Thumb Grip Rotating Handle Arm Retainer Pin Knurled Mandrel Grip Blade Arm Aluminum Mandrel Blade WARNING: The MTD PolyPeel is equipped with a small but very sharp blade which can cause injuries to operator if incorrectly handled.
-
Page 10: Replacement Parts
REPLACEMENT PARTS Part Number Description Consists of TRI1962-10 Machine Screw & Washer Figures 1 & 2 TRI1962 Replacement Blade Figure 3 TRI1962-20 Set Spring Figure 4 TRI1962-30 Set Pin Figure 5 TRI1962-40 Set Clip Figure 6... - Page 12 | 800-345-4726 © Copyright 2022, All Rights Reserved, ISCO Industries, Inc.
