  • Page 1 Version 1.1 Waymeter Pro Installation Manual ENGLISH ENGLISH...
  • Page 2: Table Of Contents

    This document and any information disclosed in connection herewith (collectively, the “Information”), whether written or oral, is the property of Enel X Way S.r.l. The Information is intended only for the person or entity to which it is presented or addressed and may contain information that is privileged, confidential, or otherwise protected from disclosure.
  • Page 3: Waymeter Pro Kit By Gavazzi Installation Guidelines

    EVs. With Enel X “Load Optimization Pro” addon, vehicles are charged respecting the residual available power at customer’s site, balancing the charging power over multiple charging stations.
  • Page 4: Waymeter Pro Kit By Gavazzi - Sales Information

    (C&I grade) and is required to activate Load Optimization Pro. It consists of 4 mains components + options: > Gateway/data logger: collect the data from the meter and send to the Enel X Cloud systems. Is connected to internet via Ethernet port >...
  • Page 5: Pre-Sales Checklist

    > If ETH or Wi-fi → Verify firewall policy on customer’s site (interfacing with site IT department and/or facility manager). Port used by Waymeter Pro Kit are listed below and are all mandatory. > If cellular → verify cellular coverage...
  • Page 6 Version 1.1 DESCRIPTION ENDPOINT PORT ENVIRONMENT NOTE c33s04psko2pez.creden- HTTPS+MQTT: Temporary tials.iot.eu-central-1.ama- 443, 8443, NO-PROD credentials zonaws.com 8883, 1883 ax3v62h9b8tp2-ats.iot. HTTPS+MQTT: IoT Broker eu-central-1.amazonaws. 443, 8443, NO-PROD 8883, 1883 c3kcoqjijz8hok.credentials. HTTPS+MQTT: Temporary iot.eu-central-1.amazo- 443, 8443, PROD credentials naws.com 8883, 1883 a3869psk1nkr1c-ats.iot. HTTPS+MQTT: IoT Broker eu-central-1.amazonaws.
  • Page 7: Ordering Info

    Version 1.1 > Switch board DIN space availability → > Gateway: 2 DIN modules > Power Supply: 3 DIN modules > Meter: please refer to Annex 1 – Meter comparison for DIN requirements > Cellular Interface: 2 DIN modules that need to be connected directly to left side of the gateway using special connector >...
  • Page 8: Waymeter Pro Kit By Gavazzi - Installation

    3. Waymeter Pro Kit by Gavazzi – Installation 3.1. Pre-Installation Checklist > If the Waymeter Pro Kit is part of installation of Charging Stations, we suggest installing Waymeter Pro Kit, when the circuit braker installation is performed. This will minimize time and effort. >...
  • Page 9: Wiring Activities

    > This meter need to be wired to COM2, while the main meter to COM1 > Waymeter Pro Kit by Gavazzi devices can be installed wherever is possible (main panel or subpanel), depending on installation scenario. > All the necessary wiring (CTs, Ethernet, etc) need to be setup accordingly. In case you need to extend CT cable, please refer to datasheet for the correct cable type.
  • Page 10 Version 1.1 See next image, for more details about wiring. WIRING SCHEMA EXAMPLE Following, some examples of wiring are showed as example. Please refer to meter installation manual for the correct wiring, depending on model and grid configuration. WIRING EXAMPLE – METER: EM210 – EU...
  • Page 11 Version 1.1 WIRING EXAMPLE – METER: EM340 – EU WIRING EXAMPLE – METER: EM330 – UL...
  • Page 12 Version 1.1 WIRING EXAMPLE – METER: WM15 – UL WIRING EXAMPLE – METER: EM530 (3P+N) – UL...
  • Page 13 Version 1.1 WIRING EXAMPLE – METER: EM530 (2P+N) – UL...
  • Page 14: Waymeter Pro Kit By Gavazzi - Software Configuration

    IP policy for the gateway (static IP or DHCP) in case of Ethernet or Wi-Fi connectivity), that must be provided bycustomer’s facility manager or its IT department > Configuration Mail, sent by Enel X Control Room or technical sales representative 4.2. Configure the gateway via UWP3 Tool PC SETUP FOR UWP CONFIGURATION...
  • Page 15 Version 1.1 the Ethernet port, just in case the primary IPaddress is not known anymore (in that case, the address to be set on pc = 192.168.253.2 Mask 255.255.255.0) > To change your PC IP address: > Open network connection or you can easily go on Start\Run and put “ncpa.cpl” and press run.
  • Page 16 Version 1.1 > Confirmation of connection with the instrument will be indicated by the green LED next to the address of the instrument in the lower left part of the screen (“PRG”) > Save the address and proceed to the following steps of the procedure. SOFTWARE CONNECTION When starting the software, in the lower left section of the window you can find the string where to enter the address of the instrument and make the connection using the “connect”...
  • Page 17 Version 1.1 PROJECT DETECTION FROM THE DEVICE NOTE: Note: this operation is not necessary for the first configuration of UWP 3 It is recommended, in order to preserve the integrity of the software on the device, that every time you connect to an instrument, carry out the “reading from the controller” (appropriate button on the bar functions as image below) and save the project as a backup on your pc.
  • Page 18 Version 1.1 SETTING THE TIME AND NTP SERVER The next step includes the setting the time on the controller: > In the “system setting” section, select “set date and time”; > Click on the Green check icon to enable field >...
  • Page 19 Follow the instructions of the Wi-Fi gateway to set up the instrument. Once configured, connect it to the UWP 3 ethernet port. INTERNET CONNECTION VIA CELLULAR MODEM The Waymeter Pro Kit can include the use of cellular modem, which can be set with the following steps: >...
  • Page 20: Configure The Meter Settings

    Version 1.1 Below is the screenshot of a USB router configuration: Now, send the configuration to the controller by clicking on “Send to controller” button on the toolbar on top of the screen. It’s important to send the configuration now, since the gateway has no configuration onboard and the following step will be not accessible.
  • Page 21 Version 1.1 Below is a brief description of the configuration steps to be carried out: > From the menu at the top left select “Service” and then “CG Secure Bridge” > Enable “Secure Communication” and change the password as indicated in the configuration file >...
  • Page 22 Version 1.1 > Select “Manual” and insert the IP address of the UWP3 controller and click “Connect” > Fill the information in the window: > If UWP Secure bridge service (cfr. Enable UWP Secure Bridge) is password protected, insert the password >...
  • Page 23: Meter Data Management

    Gavazzi software library; the software is equipped with all the drivers referring to Carlo Gavazzi instruments and provides the possibility of creating special drivers for the connection of third-party instruments (not needed for Waymeter Pro Kit).
  • Page 24 Version 1.1 Below is the screenshot of the configuration of the parameters referring to the Modbus of a device:procedure to configure it The procedure for adding a new device under the COM port is terminated after confirming the popup, however it is now necessary to upload the project created so far to the device. It is therefore necessary, after verifying that the UWP controller is connected via the green LED on the lower left side, to press the “send to controller”...
  • Page 25 Version 1.1 > From the “database manager” window it will be possible to flag the datapoints to be selected indicated in the configuration mail that was provided by country control room or technical sales. For each data point (“Name” column), the historical mode (“Data log”) must be selected and the “AVG”...
  • Page 26: Web Platform And Enel X Cloud Connection

    4.5. Web platform and Enel X cloud connection The last configuration step involves the connection with the Enel X cloud and the synchronization of the logs to the IoT platform. With reference to this section, it will be necessary to have the configuration mail.
  • Page 27 Version 1.1 > In the “services” menu, selecting “EnelX IoT service” you need to insert all the information for the configuration of the connection to the IoT cloud, as indicated in the configuration mail. To avoid mistake, it’s suggested to use copy/paste feature, paying attention that there is no blank/space at the end of the files after the paste action.
  • Page 28: Closing Activity

    Once the entire data has been filled, it will be necessary to communicate the end of the activity to the Enel X country control room or technical sales, which will start the activation of the things through specific payloads directly from the IoT platform.
  • Page 29: Troubleshooting

    Version 1.1 5. Troubleshooting 5.1. Gateway Factory Reset Those operations must be done only if asked by Enel X FACTORY RESET THE GATEWAY This operation will completely delete all the settings from the gateway and will delete the association with Enel X Cloud >...
  • Page 30: Annex 1 - Meter Comparison

    Version 1.1 6. Annex 1 – Meter comparison METER EM111 EM340 EM210 EM330 EM530 WM15 System (Phase) 1, 2, 3 1, 2, 3 1, 2, 3 160 to 240 120 to 240 V L-N 277 V L-N 208 120 to 230 230 to 277 to 415 V 120 to 240...
  • Page 31: Annex 2 - Sensor Comparison And Compatibility

    Version 1.1 7. Annex 2 – Sensor comparison and compatibility MODEL ROG* Code CTD [x] X … CTD [x] S … CTA … CTV … ROG4… Core Solid Split Split Split Busbar/ Mounting Busbar Cable Cable Busbar/cable cable Already wired Already wired Already wired (cable Cabling...
  • Page 32: Annex 3 - Ordering Information

    Version 1.1 8. Annex 3 – Ordering information EUROPE/CE ENEL X PART BRAND CATEGORY CG PN DESCRIPTION NUMBER Gateway and Gavazzi UWP30RSEXXX 8030956085242 153-000290 Gateway Accessories Gateway and Gavazzi SPMA24301 5350035433645 153-000291 Power Supply Accessories Gateway and 96x96 adaptor for...
  • Page 33: Annex 4 - Meter Configuration

    Version 1.1 9. Annex 4 – Meter configuration ATTRIBUTE ATTRIBUTE METER PARAMETER NAME ON UCS NAME ON VALUE NOTE MODEL TOOL DISPLAY VT primary i.e. for CTV-2X Voltage sensor EM111 (only in case Pri Curr CT→Primary Current 100A 333MV, CT primary current of CT) primary is 100...
  • Page 34 Version 1.1 Ct→VT sensors Sensor Type Sensor Selection SEnSOR Rog→Rogowski 100mV VT primary i.e. for CTV-2X Voltage transfor- (only in case Ct Prin CT→Primary Current 100A 333MV, CT mer ratio of CT) primary is 100 Rogowski “1,00k”, that means please select the Range 1000A upper value (in...
