Lime Generation 3.0 Replacement

Central console replacement
Hide thumbs Also See for Generation 3.0:

Advertisement

Quick Links

Download this manual
Generation 3.0
Central Console
Replacement
3/1/2019
Central Repair-Lime Technical Institute

Advertisement

loading
Need help?

Need help?

Do you have a question about the Generation 3.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Lime Generation 3.0

Summary of Contents for Lime Generation 3.0

  • Page 1 Generation 3.0 Central Console Replacement 3/1/2019 Central Repair-Lime Technical Institute...
  • Page 2 Tools List 1.T-handle Wrench - Torx 2.Philips Screwdriver Torx Wrench Phillips...
  • Page 3 3.0 Central Console Disassembly SOP Technical Guideline Video Link...
  • Page 4 1. Remove the Center Console Cover 2min Tools -T10 Torx Wrench Part (none) CAUTION STEP 1 STEP 2 Use a T10 wrench to loosen the two screws on the Tear off the stickers on the left and right sides, top and bottom. then loosen the screws with a T10 wrench.
  • Page 5 2. Remove the Center Console Screws 1min Tools -Phillips Screwdriver Part CAUTION Pull out the headlight wire on the right side first to avoid breaking the wire. STEP 4 STEP 3 Use a Phillips screwdriver to remove the 4 screws Remove the central control cover.
  • Page 6 3. Remove the Center Console 1min Tools (none) Part (none) CAUTION If the wires are unplugged in the neck, or fall back into STEP 6 STEP 5 the neck, they are Unplug the wire connectors. Make sure the wires Pull out the central control wires carefully, making extremely hard to do not fall in the neck.
  • Page 7 3.0 Central Console Assembly SOP Technical Guideline Video Link...
  • Page 8 1. Connect the New Center Console 1min Tools (none) Part -Working Center Console CAUTION STEP 1 STEP 2 Connect the center console terminals. Insert the central control wire carefully into the neck hole.
  • Page 9 2. Replace the Center Console Screws and Cover 2min Tools -Philips Screwdriver Part (none) CAUTION STEP 4 STEP 3 Use a Phillips screwdriver to tighten the 4 screws, Place the protective cover. and then route the headlight wire under the center control.
  • Page 10 3. Replace the Center Console Screws 2min Tools -T10 Torx Wrench Part (none) CAUTION STEP 5 STEP 6 Tighten the three screws on the left and right with Tighten the top and bottom screws with a T10 a T10 wrench. wrench.
  • Page 11 4. Replace the Stickers Tools (none) Part (none) CAUTION STEP 7 STEP 8 Stick the left sticker. Stick the right sticker.
  • Page 12 Remember to quality check & test ride. Wrench On!
