Aerophone Pro Editor
Owner's Manual
© 2020 Roland Corporation
04

Advertisement

loading
Need help?

Need help?

Do you have a question about the Aerophone Pro Editor and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roland Aerophone Pro Editor

Summary of Contents for Roland Aerophone Pro Editor

  • Page 1 Aerophone Pro Editor Owner’s Manual © 2020 Roland Corporation...
  • Page 2 Aerophone Pro Editor Contents Preparing to Use Aerophone Pro Editor Connecting with the Aerophone About Aerophone Pro Editor Using FAVORITE Using the FAVORITE Screen Using EDITOR Setting the Parameter Values Turning all effects off Using the EDITOR Screen SCENE VIEW...
  • Page 3 Contents Preparing to Use Aerophone Pro Editor “Aerophone Pro Editor” Connect the app installed on your mobile device to the Aerophone via Bluetooth. * When using on Android 6.0 or later, please turn Android Location mode on. Connecting with the Aerophone Turn the Aerophone on.
  • Page 4 Contents Preparing to Use Aerophone Pro Editor Start Aerophone Pro Editor. Tap the [CONNECT] button on the screen. * If more than one Aerophone is detected, a selection screen appears. * If the mobile device was already connected to an Aerophone, it automatically connects to that unit again, even if more than one Aerophone is detected.
  • Page 5 Contents About Aerophone Pro Editor Aerophone Pro Editor has the following functions. To switch between functions, use the buttons at the bottom of the screen. FAVORITE SETUP Lets you check and switch Configures the connection between the currently settings with the Aerophone, selected scene, or register and shows the Owner’s...

  • Page 6: Using Favorite

    Contents Using FAVORITE Using FAVORITE Using the FAVORITE Screen MEMO Buttons that are marked with the “ ” symbol can be pressed and held to display other windows or to switch to a different screen (this works the same with the EDITOR). The currently selected scene is Tap the icon to show all shown.
  • Page 7 Contents Using EDITOR Setting the Parameter Values Operate the app as shown below to set a parameter’s value. * You can scroll the parameter list up/down. Setting a value When you tap a value, a controller appears. Tap a value and hold the controller down to display the numeric keypad or list.
  • Page 8 Contents Using EDITOR Turning all effects off SCENE VIEW Tap “Scene Effects” in and turn all the effects off. SCENE VIEW Tap the MFX for each part in to turn them all off. Press the [WRITE] button in SCENE VIEW to save the scene.
  • Page 9 Contents Using EDITOR Using the EDITOR Screen SCENE VIEW [WRITE] button The currently selected Tap this to switch scene is shown. between scenes to edit. Saves the scene you are now editing as an * Hold this down to display the scene name edit Aerophone user scene.

  • Page 10: Part View

    Contents Using EDITOR PART VIEW Hold down parts 1–4 in SCENE VIEW to display the edit screen (PART VIEW) for the part you pressed. [COPY] button [WRITE] button Tap to return to the previous screen. Switches to the PART Saves the scene you COPY screen.
  • Page 11 Contents Using EDITOR TONE VIEW In PART VIEW, tap the [EDIT] button for the tone to display the edit screen (TONE VIEW) for that tone. Tap to return to the Tap this to switch [WRITE] button previous screen. between tones to edit. Saves the tone you are now editing as an Aerophone user tone.
  • Page 12 Contents PARTIAL VIEW Hold down partial 1–4 in TONE VIEW to display the edit screen (PARTIAL VIEW) for the partial you pressed. [COPY] button [WRITE] button Tap to return to the previous screen. Switches to the PARTIAL Saves the tone you COPY screen.
  • Page 13 Contents Using LIBRARIAN Using LIBRARIAN Using the LIBRARIAN Screen [SELECT] button Creates an empty library. Imports/exports the scene data. Copies or deletes a library. Shows the SCENE LIST screen. Shows a list of libraries. The number of scenes registered in each library Select the scenes to is shown below the library import.
  • Page 14 Contents Using LIBRARIAN Using the SCENE LIST Screen [SELECT] button Copies or deletes a scene. The list of scenes is shown Edits the scene name. here. The number of user tones registered to a scene is shown at the end of the scene name.
  • Page 15 Contents Using LIBRARIAN Importing a Scene from the Aerophone into LI- BRARIAN In the upper part of the LIBRARIAN screen, tap the (IMPORT) button. Tap “Aerophone,” and then tap the [NEXT] button. Select the scenes to import. MEMO When you select a scene that uses user tones, the user tones are also imported. Select the library to which you want to import.
  • Page 16 Contents Using LIBRARIAN Exporting a Scene from LIBRARIAN into the Aerophone In the upper part of the LIBRARIAN screen, tap the (EXPORT) button. Tap “Aerophone,” and then tap the [NEXT] button. Select the scenes to export. Select the location where you want to export the scenes. If the scenes use user tones, you can also choose where to export the tones.
  • Page 17 Contents Using LIBRARIAN Exporting the Libraries from LIBRARIAN to a Mobile Device or Cloud Service You can convert the LIBRARIAN libraries into files and export them to your mobile device or to a cloud service. In the upper part of the LIBRARIAN screen, tap the (EXPORT) button.
  • Page 18 Contents Using LIBRARIAN Importing a Scene from a Mobile Device or Cloud Service to LIBRARIAN In the upper part of the LIBRARIAN screen, tap the (IMPORT) button. Tap “File” or “Cloud” (on your mobile device) (the cloud service to use) tap the [NEXT] button.

  • Page 19: Using Setup

    Explanation Displays the screen for connecting with the Bluetooth Device Aerophone. Sets whether to display the Bluetooth Setup Application Setting screen when the Aerophone Pro Editor starts. Displays the Aerophone Pro Editor Owner’s Manual Manual (this document). Displays the system program versions and...
