Summary of Contents for TZS First AUSTRIA 22BF08
- Page 1 USER GUIDE STEREO WIRELESS HEADSET MODEL: 22BF08 THANK YOU FOR CHOOSING TZS BACKGROUND NOISE REDUCTION FOR CALLS...
- Page 2 In the Box 3.5mm Audio Cable Headset Type-C Charging Cable User Guide...
- Page 3 Overview Boom microphone Play/Pause Answer calls /End calls Next track Previous track Mute microphone switch Indicator Type C charging port...
-
Page 4: How To Wear
How to Wear 1. The boom microphone can move to accommodate a user’s preference for right side or left side wear. 2. Position the microphone to your preference. -
Page 5: Operation
Operation Power On Press and hold the for 3 seconds Power Off Press and hold the for 3 seconds... -
Page 6: Previous/Next Song
Volume +/- Click the + button to increase the volume, click the - button to decrease the volume. Previous/Next song Press and hold the + button to skip to the next song, press and hold the - button to skip to the previous song. - Page 7 Connecting 1. How to connect with the Bluetooth device. Bluetooth Bluetooth Devices TZS TP-BF03 Paired Now discoverable Press and hold the button Activate "Bluetooth" in your 3S 'power on' head, the pairing device‘s settings and select LED will be ash, and 'pairing' ”TZS TP-BF03.
- Page 8 2. How to connect with two Bluetooth devices. Bluetooth Bluetooth Bluetooth TZS TP-BF03 Devices TZS TP-BF03 Paired Now discoverable Device 1 Device 2 When you rst device connected successfully, switch the rst device Bluetooth o , activate your second device Bluetooth，connect the headphone, and then activate the rst device Bluetooth, the headphone will be reconnected the rst device, and then the headphone connected the 2...
- Page 9 Calls with a Smartphone Calls with a Smartphone Answer Press 1 × Press 1 × End Call Press and hold Decline 2 seconds Siri/Cortana/Assistance Press and hold 2 seconds then release...
-
Page 10: Charging The Headset
Charging the Headset During charging the red LED will light. When fully charged, the LED will turn o . The headset will be o during the charging. Plug the USB-C charging cable into a computer’s USB port. Plug the USB-C charging cable into a USB wall charger. -
Page 11: Other Operations
Other Operations Muting the Boom Mic: Switch the mute button to the off Clearing the pairing: Press and hold the for 10 seconds while the headset is off... -
Page 12: Product Specifications
Product Specifications Bluetooth version: Bluetooth V5.0 Bluetooth Profile: A2DPv1.3.1; AVRCPv1.6; HFPv1.7; HSPv1.2; SPP v1.2; DID v1.3; HID v1.1; PXP v1.0.1; FMP v1.0; BAS v1.0 Working Frequency: 2.402GHz-2.480GHz Frequency Response: 104±3dB Receiving sensitivity: >-89dBm Battery type: Lithium polymer Mic type and sensitivity: Virtual Microphone -42±3dB Headphone Driver Size: 30mm Battery capacity: 400mAh DC Input: 5V_500MA... -
Page 13: Safety Information
WARNING Headsets can deliver sounds at loud volumes and high-pitched tones. Avoid prolonged use of the headset at excessive sound pressure levels. Please read the safety guidelines below prior to using this headset. Safety information Use of a headset will impair your ability to hear other sounds. Use caution while using your headset when you are engaging in any activity that requires your full attention. -
Page 14: Battery Warning
Always try to keep the battery between 15°C and 25°C (59°F and 77°F). A product with a hot or cold battery may not work temporarily, even when the battery is fully charged. Battery performance is particularly limited in temperatures well below freezing. -
Page 15: Troubleshooting And Support
Troubleshooting & Support Headphones will not power on: • Be sure the headphones are fully charged. After successfully pairing, the headphones disconnect • Be sure the battery has adequate power and recharge. • Headphones must be within 10m of most mobile devices. •... - Page 16 There is no sound when listening to music • Increase the volume on your headphones or the mobile device. • Reestablish the Bluetooth wireless connection between the headphones and your mobile device. • Check if the audio app has paused or stopped playback. Headphones will not charge •...
-
Page 17: Fcc Statement
FCC Statement Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
