Operation, Maintenance, and Parts Manual for MCS3
SHEATHING/DECKING STAPLER
MODEL ........................................................... MCS3
AIR INLET........................................................ 1/4" NPT
WEIGHT .......................................................... 4 lbs. 6 ozs.
LENGTH .......................................................... 13.9"
HEIGHT ........................................................... 10.5"
MAXIMUM PRESSURE .................................. 125 PSI
PRESSURE RANGE......................................... 75-120 PSI
FASTENER LENGTHS .................................... 1" - 2"
CROWN SIZE .................................................. 7/16"
MAGAZINE CAPACITY .................................. 120 Staples
SCFM REQUIRED @ 90 PSI ........................... Every 10 Fasteners
MINIMUM COMPRESSOR HP
REQUIRED TO OPERATE ............................... 3/4 HP
This manual contains information that is important for you to know and understand.
This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT
PROBLEMS. PLEASE READ THIS MANUAL.
MGP-MCS3-1A 9/25/97
STEEL DRIVER SERIES
Specifications
DeVilbiss Air Power Company • 213 Industrial Drive • Jackson, TN 38301-9615
Delivered Per Minute
Requires 1.12 SCFM
(TANK MOUNTED)
Advertisement
Table of Contents
Related Manuals for DeVillbiss Air Power Company Steel Driver Series
Summary of Contents for DeVillbiss Air Power Company Steel Driver Series
- Page 1 STEEL DRIVER SERIES Operation, Maintenance, and Parts Manual for MCS3 SHEATHING/DECKING STAPLER Specifications MODEL ............MCS3 AIR INLET............1/4" NPT WEIGHT ............4 lbs. 6 ozs. LENGTH ............13.9" HEIGHT ............10.5" MAXIMUM PRESSURE ........125 PSI PRESSURE RANGE......... 75-120 PSI FASTENER LENGTHS ........
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE Tool Specifications..................Front Cover Table of Contents ....................... 2 Limited Warranty ......................3 Safety Guidelines ....................... 4 Warning Chart ......................4-6 Lubrication and Maintenance ..................7-8 Recommended Hook-up.................... 8 Contact Trip Safety Mechanism ................9 A. Operating A Contact Trip Tool B. -
Page 3: Limited Warranty
LIMITED WARRANTY ONE YEAR FROM DATE OF PURCHASE All merchandise manufactured by DeVilbiss Air Power Company is warranted to be free of defects in workmanship and material which occur during the first year from the date of purchase by the original purchaser (initial user). Products covered under this warranty include: air compressors, *air tools, accessories, service parts, pressure washers, and generators used in consumer applications (i.e., personal residential household usage only). -
Page 4: Safety Guidelines
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know Information for preventing damage to URGENT SAFETY INFORMATION - A HAZARD and understand. This information equipment. THAT WILL CAUSE SERIOUS INJURY OR LOSS relates to protecting YOUR OF LIFE. - Page 5 SAFETY GUIDELINES DANGER Read these warnings carefully. Failure to follow warnings will result in severe injury or death! Risk of head injury. HAZARD TO LOOK FOR WHAT COULD HAPPEN HOW TO PREVENT IT Metal fragments, fasteners, or other ma- Always wear ANSI approved Z87 safety njury to eyes, head and hearing.
- Page 6 SAFETY GUIDELINES Risk of puncture injury. HAZARD TO LOOK FOR WHAT COULD HAPPEN HOW TO PREVENT IT Connecting and Disconnecting Accidental discharge of a fastener can Hold tool by the handle and keep trigger Air Hose. occur. and contact trip safety mechanism from contacting objects or parts of the body when connecting or disconnecting air supply.
-
Page 7: Lubrication And Maintenance
LUBRICATION AND MAINTENANCE NOTE Many air tool users find it convenient to use an Oiler to help provide oil circulation through tool. An Oiler also increases the efficiency and useful life of the tool. An oiler is recommended for tools that receive heavy or constant use. -
Page 8: Recommended Hook-Up
LUBRICATION AND MAINTENANCE Always connect the Female Quick Coupler to the air Do not use any type of flammable gases or oxygen as a hose. Never connect the Female Quick Coupler to the power source for the tool. Use filtered, lubricated, regu- tool. -
Page 9: Contact Trip Safety Mechanism
CONTACT TRIP SAFETY MECHANISM The trigger is released after each fastener is driven. Move the tool to the next desired fastener location and repeat the procedure above. CHECKING THE OPERATION OF Never keep the trigger pulled on contact trip tools CONTACT TRIP SAFETY MECHANISM when carrying or holding the tool. -
Page 10: Loading The Tool
LOADING THE TOOL Disconnect tool from air supply before adjusting, Handle the tool carefully, respect the tool as a working clearing jams, servicing, relocating and during non- implement and always assume the tool contains operation. fasteners: a. Never use the tool as a toy and engage in horse- play. -
Page 11: Clearing A Jam From The Tool
OPERATING THE TOOL 1. Add one drop of Air Tool Oil, high speed spindle oil, 4. Test for proper fastener penetration by driving fasteners such as Unocal RX22, or 3-in1 oil into the air inlet. into a sample piece of wood. If the fasteners do not achieve the desired penetration, adjust the air pressure 2. -
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE Stop using the Tool immediately if any of the following occur. Serious personal injury could occur. Warranty repairs or replacements must be performed by a DeVilbiss Air Power Authorized Service Center Only. SOLUTION PROBLEM CAUSE Seals in trigger shaft valve housing are damaged. Seals must be replaced. -
Page 13: Exploded View
EXPLODED VIEW... -
Page 14: Parts List
PARTS LIST P A R T P A R T NUMBER NUMBER DESCRIPTION DESCRIPTION NSP-120 Screw NSP-178 NSP-182 Washer NSP-133 Plate, Guide Body NSP-034 Exhaust Deflector NSP-177 Latch Assy. ----- Seal NSP-134 Door NSP-033 NSP-132 Screw ----- Seal NSP-038 Guide Body ----- Spring NSP-183... -
Page 15: Fasteners
FASTENERS Crown Shank Fastener Shank Type Finish Length Gauge Collation Part # Head Type Galvanized 1 1/2" 16 GA Adhesive 3MC38 10,000 7/16" Crown Coated Galvanized 1 3/4" 16 GA Adhesive 3MC45 10,000 7/16" Crown Coated INTERCHANGE INFORMATION The DeVilbiss Sheathing/Decking Stapler, will accept Fasteners for: Senco M1 &... - Page 16 Retain the original sales receipts as proof of purchase STEEL DRIVER SERIES for warranty repair work. Operating, Maintenance and Parts Attach sales receipt here. Manual for MCS3 Sheathing/Decking Stapler Call our Toll Free Number 1-800-888-2468, Ext 2, then 1, to obtain the location of the nearest Authorized Service Center for ordering repair parts and for warranty repairs.
