DeVillbiss Air Power Company STEEL DRIVER Series Operation, Maintenance And Parts Manual

Medium duty stapler

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Operation, Maintenance, and Parts Manual for NCS2

MEDIUM DUTY STAPLER

MODEL .................................................... NCS2

AIR INLET ....................................................... 1/4" NPT

WEIGHT .......................................................... 2 lbs. 8 ozs.

LENGTH .......................................................... 9.5"

HEIGHT ........................................................... 7"

MAXIMUM PRESSURE .................................. 125 PSI

PRESSURE RANGE ....................................... 65-100 PSI

FASTENER LENGTH ...................................... 1/2" - 1"

CROWN SIZE ................................................. 1/4"

MAGAZINE CAPACITY .................................. 100 Staples

SCFM REQUIRED @ 90 PSI .......................... Every 10 Fasteners

MINIMUM COMPRESSOR HP

REQUIRED TO OPERATE .............................. 3/4 HP

This manual contains information that is important for you to know and under-

stand. This information relates to protecting YOUR SAFETY and PREVENTING

EQUIPMENT PROBLEMS. PLEASE READ THIS MANUAL.

MGP-NCS2-1A 9/25/97

STEEL DRIVER SERIES

Specifications

DeVilbiss Air Power Company • 213 Industrial Drive • Jackson, TN 38301-9615

Delivered Per Minute

Requires .25 SCFM

(TANK MOUNTED)

Table of Contents

Need help?

Do you have a question about the STEEL DRIVER Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DeVillbiss Air Power Company STEEL DRIVER Series

Page 1 STEEL DRIVER SERIES Operation, Maintenance, and Parts Manual for NCS2 MEDIUM DUTY STAPLER Specifications MODEL ............ NCS2 AIR INLET ............1/4" NPT WEIGHT ............2 lbs. 8 ozs. LENGTH ............9.5" HEIGHT ............7" MAXIMUM PRESSURE ........125 PSI PRESSURE RANGE ........65-100 PSI FASTENER LENGTH ........
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE Tool Specifications ..................Front Cover Table of Contents ......................2 Limited Warranty ......................3 Safety Guidelines ......................4 Warning Chart ......................4-6 Lubrication and Maintenance ..................7-8 Recommended Hook-up ....................8 Contact Trip Safety Mechanism ..................9 A.
Page 3: Limited Warranty
LIMITED WARRANTY ONE YEAR FROM DATE OF PURCHASE All merchandise manufactured by DeVilbiss Air Power Company is warranted to be free of defects in workmanship and material which occur during the first year from the date of purchase by the original purchaser (initial user). Products covered under this warranty include: air compressors, *air tools, accessories, service parts, pressure washers, and generators used in consumer applications (i.e., personal residential household usage only).
Page 4: Safety Guidelines
SAFETY GUIDELINES - DEFINITIONS This manual contains informa- tion that is important for you to Information for preventing damage to URGENT SAFETY INFORMATION - A HAZARD know and understand. This infor- equipment. THAT WILL CAUSE SERIOUS INJURY OR LOSS mation relates to protecting YOUR OF LIFE.
Page 5 SAFETY GUIDELINES DANGER Read these warnings carefully. Failure to follow warnings will result in severe injury or death! Risk of head injury. HAZARD TO LOOK FOR WHAT COULD HAPPEN HOW TO PREVENT IT Metal fragments, fasteners, or other ma- Always wear ANSI approved Z87 safety njury to eyes, head and hearing terial could be projected against head or glasses, Z89.1 head protection and...
Page 6 SAFETY GUIDELINES Risk of puncture injury. HAZARD TO LOOK FOR WHAT COULD HAPPEN HOW TO PREVENT IT Connecting and Disconnecting Accidental discharge of a fastener can Hold tool by the handle and keep trigger Air Hose occur. and contact trip safety mechanism from contacting objects or parts of the body when connecting or disconnecting air supply.
Page 7: Lubrication And Maintenance
LUBRICATION AND MAINTENANCE NOTE Many air tool users find it convenient to use an Oiler to help provide oil circulation through tool. An Oiler also increases the efficiency and useful life of the tool. An oiler is recommended for tools that receive heavy or constant use.
Page 8: Recommended Hook-Up
LUBRICATION AND MAINTENANCE Always connect the Female Quick Coupler to the air hose. Do not use any type of flammable gases or oxygen as a Never connect the Female Quick Coupler to the tool. power source for the tool. Use filtered, lubricated, regu- lated compressed air only.
Page 9: Contact Trip Safety Mechanism
CONTACT TRIP SAFETY MECHANISM The trigger is released after each fastener is driven. Move the tool to the next desired fastener location and repeat the procedure above. CHECKING THE OPERATION OF Never keep the trigger pulled on contact trip tools CONTACT TRIP SAFETY MECHANISM when carrying or holding the tool.
Page 10: Loading The Tool
LOADING THE TOOL Disconnect tool from air supply before adjusting, Handle the tool carefully, respect the tool as a work- clearing jams, servicing, relocating and during non- ing implement and always assume the tool contains operation. fasteners: a. Never use the tool as a toy and engage in horse- play.
Page 11: Clearing A Jam From The Tool
OPERATING THE TOOL 1. Add one drop of Air Tool Oil, high speed spindle oil, 5. Load fasteners into your tool following the instruction in such as Unocal RX22, or 3-in1 oil into the air inlet. this manual. 2. Attach a Quick Connect Fitting to the tool. 6.
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE Stop using the tool immediately if any of the following occur. Serious personal injury could occur. Warranty repairs or replacements must be performed by a DeVilbiss Air Power Authorized Service Center Only. PROBLEM SOLUTION CAUSE Air leaking at trigger valve area. Seals must be replaced &...
Page 13: Exploded View
EXPLODED VIEW...
Page 14: Parts List
PARTS LIST PART PART NUMBER DESCRIPTION DESCRIPTION NUMBER NSP-154 Screw NSP-146 Retainer NSP-182 Washer NSP-163 NSP-074 Exhaust Deflector NSP-093 Inner Trigger ----- Spring NSP-095 Trigger ----- Seal NSP-096 NSP-077 Cylinder Cap Assy. NSP-065 Shaft ----- Seal NSP-094 Spring ----- Seal NSP-097 Main Body Assy.
Page 15: Fasteners
FASTENERS Crown Shank Fastener Shank Type Finish Length Gauge Collation Part # Head Type Galvanized 5/8" 18 GA Adhesive 2L16 5,000 1/4" Galvanized 2L19 3/4" 18 GA Adhesive 5,000 1/4" Galvanized 1" 18 GA Adhesive 2L25 5,000 1/4" INTERCHANGE INFORMATION The DeVilbiss Medium Duty Stapler NCS2, will accept Fasteners for: Bostitch TA52...
Page 16 Retain the original sales receipts as proof of purchase for warranty repair work. STEEL DRIVER SERIES Attach sales receipt here. Operating, Maintenance and Parts Manual for NCS2 Medium Duty Stapler Call our Toll Free Number 1-800-888-2468, Ext 2, then 1, to obtain the location of the nearest Authorized Service Center for ordering repair parts and for warranty repairs.
