Access & Power Integration
Altronix/Kisi Kits
Models Include:
T1KE3F4
4 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) eFlow6NB - Power Supply/Charger
- One (1) ACM4 - Fused Access Power Controller
T1KE3F8
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) eFlow6NB - Power Supply/Charger
- Two (2) ACM4 - Fused Access Power Controllers
T2KE33F16
16 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TLU2 backplane
- Two (2) eFlow6NB - Power Supply/Charger
- Two (2) ACM8 - Fused Access Power Controllers
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. 111722
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T1KE3F4D
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) eFlow6NB - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
T1KE3F8D
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) eFlow6NB - Power Supply/Charger
- Two (2) ACM4CB - PTC Access Power Controllers
T2KE33F16D
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TLU2 backplane
- Two (2) eFlow6NB - Power Supply/Charger
- Two (2) ACM8CB - PTC Access Power Controllers
More than just power.™
Advertisement
Related Manuals for Altronics T1KE3F4
Summary of Contents for Altronics T1KE3F4
- Page 1 Access & Power Integration Altronix/Kisi Kits Models Include: T1KE3F4 T1KE3F4D 4 Door Kit with Fused Outputs 4 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove1 enclosure with TLU1 backplane - Trove1 enclosure with TLU1 backplane...
-
Page 2: Configuration Chart
Fuse Fuse Access Power Controllers’ Range Range Fail-Secure Fuse Fuse Number Rating Rating outputs (VDC) (VDC) Outputs Rating Rating Rating T1KE3F4 3A/32V – 10A/32V T1KE3F4D – 2.5A T1KE3F8 3A/32V – 10A/ 20.17- 20.28- 24VDC @ 5.7A 10A/32V 250V 26.4 26.4 T1KE3F8D –... - Page 3 T1KE3F4 and T1KE3F4D: Configuration of Kisi Pro Controllers: 1. Fasten mounting magnets (provided) to Kisi Pro Controllers with screws and spacers (provided) using the controllers’ mounting holes (Fig. 2, pg. 3). 2. Attach mounting magnets to TLU1 in the approximate position as shown below (Fig. 2a, pg. 3).
- Page 4 T1KE3F8 and T1KE3F8D: Configuration of Kisi Pro Controllers: 1. Fasten mounting magnets (provided) to Kisi Pro Controllers with screws and spacers (provided) using the controllers’ mounting holes (Fig. 3, pg. 4). 2. Attach mounting magnets to TLU1 in the approximate position as shown below (Fig. 3a, pg. 4). Note: Kisi Pro Controllers should be properly oriented.
- Page 5 T2KE33F16 and T2KE33F16D: Configuration of Kisi Pro Controllers: 1. Fasten mounting magnets (provided) to Kisi Pro Controllers with screws and spacers (provided) using the controllers’ mounting holes (Fig. 4, pg. 5). 2. Attach mounting magnets to TLU2 in the approximate position as shown below (Fig. 4a, pg. 5). Note: Kisi Pro Controllers should be properly oriented.
- Page 6 T1KE3F4(D) and T1KE3F8(D) Enclosure Dimensions (H x W x D approximate): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.3mm) 7.25” (184.2mm) 1.45” (36.8mm) 1.95” (49.5mm) 4.5” (114.3mm) 13.0” (330.2mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.5” (38.1mm) 1.5” (38.1mm) 0.6”...
- Page 7 T2KE33F16(D) Enclosure Dimensions (H x W x D approximate): 27.25” x 21.5” x 6.5” (692.2mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 5.25” (133.35mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77” 1.125” (28.3mm) (45mm) 2.415”...
- Page 8 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty. MEMBER IITrove KE eFlow Kits K17V - 8 - Trove KE eFlow Kits Installation Guide...
