Access & Power Integration
Altronix/Kisi Kits
Models Include:
T1KE3F4V
4 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) eFlow6NBV - Power Supply/Charger
- One (1) ACM4 - Fused Access Power Controller
T1KE3F8V
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) eFlow6NBV - Power Supply/Charger
- Two (2) ACM4 - Fused Access Power Controllers
T2KE33F16V
16 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TLU2 backplane
- Two (2) eFlow6NBV - Power Supply/Charger
- Two (2) ACM8 - Fused Access Power Controllers
Installation Guide
All registered trademarks are property of their respective owners.
Rev. 111722
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T1KE3F4DV
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) eFlow6NBV - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
T1KE3F8DV
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) eFlow6NBV - Power Supply/Charger
- Two (2) ACM4CB - PTC Access Power Controllers
T2KE33F16DV
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TLU2 backplane
- Two (2) eFlow6NBV - Power Supply/Charger
- Two (2) ACM8CB - PTC Access Power Controllers
More than just power.™
Advertisement
Related Manuals for Altronics TROVE T1KE3F4V
Summary of Contents for Altronics TROVE T1KE3F4V
- Page 1 Access & Power Integration Altronix/Kisi Kits Models Include: T1KE3F4V T1KE3F4DV 4 Door Kit with Fused Outputs 4 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove1 enclosure with TLU1 backplane - Trove1 enclosure with TLU1 backplane - One (1) eFlow6NBV - Power Supply/Charger - One (1) eFlow6NBV - Power Supply/Charger - One (1) ACM4 - Fused Access Power Controller...
-
Page 2: Configuration Chart
Overview: Altronix Trove Kisi kits are pre-assembled and consist of Trove1LU1 or Trove2LU2 enclosure/backplane with factory installed Altronix power supply/charger(s) and sub-assemblies. Trove Kisi kits also accommodates up to four (4) Kisi Pro Controllers for up to sixteen (16) doors in a single enclosure. - Page 3 T1KE3F4V and T1KE3F4DV: Configuration of Kisi Pro Controllers: 1. Fasten mounting magnets (provided) to Kisi Pro Controllers with screws and spacers (provided) using the controllers’ mounting holes (Fig. 2, pg. 3). 2. Attach mounting magnets to TLU1 in the approximate position as shown below (Fig. 2a, pg. 3). Note: Kisi Pro Controllers should be properly oriented.
- Page 4 T1KE3F8V and T1KE3F8DV: Configuration of Kisi Pro Controllers: 1. Fasten mounting magnets (provided) to Kisi Pro Controllers with screws and spacers (provided) using the controllers’ mounting holes (Fig. 3, pg. 4). 2. Attach mounting magnets to TLU1 in the approximate position as shown below (Fig. 3a, pg. 4). Note: Kisi Pro Controllers should be properly oriented.
- Page 5 T2KE33F16V and T2KE33F16DV: Configuration of Kisi Pro Controllers: 1. Fasten mounting magnets (provided) to Kisi Pro Controllers with screws and spacers (provided) using the controllers’ mounting holes (Fig. 4, pg. 5). 2. Attach mounting magnets to TLU2 in the approximate position as shown below (Fig. 4a, pg. 5). Note: Kisi Pro Controllers should be properly oriented.
- Page 6 T1KE3F4(D)V and T1KE3F8(D)V Enclosure Dimensions (H x W x D approximate): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.3mm) 7.25” (184.2mm) 1.45” (36.8mm) 1.95” (49.5mm) 4.5” (114.3mm) 13.0” (330.2mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.5” (38.1mm) 1.5” (38.1mm) 0.6”...
- Page 7 T2KE33F16(D)V Enclosure Dimensions (H x W x D approximate): 27.25” x 21.5” x 6.5” (692.2mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 5.25” (133.35mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77” 1.125” (28.3mm) (45mm) 2.415”...
- Page 8 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty. MEMBER IITrove KE eFlow V Kits K17V - 8 - Trove KE eFlow V Kits Installation Guide...
