- Page 1 DM 27” IPS (SHARP) 180Hz Flat QHD Gaming Monitor P/N 42892 User's Manual...
-
Page 2: Table Of Contents
Thank you for purchasing this product To ensure optimum performance and safety, read the following instructions before connecting, operating, or adjusting the product. Keep this manual for future reference. Table of Contents Safety Warnings and Guidelines ..................2 Introduction ............................4 Features .............................. -
Page 3: Safety Warnings And Guidelines
Safety Warnings and Guidelines Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. •... - Page 4 This device uses a grounded power cord and requires a ground • connection for safe operation. Ensure that the power source has a proper ground connection. Do not modify the plug or use a "cheater" plug to bypass the ground connection. Unplug this device from the power source when not in use.
-
Page 5: Introduction
8‑bit image quality, peak luminance of 400cd/m2, higher contrast ratio, and a wider color gamut. Our Dark Matter 27" Gaming Monitor features an A+ grade panel and, as with all our monitors, is backed by our 1 Year PixelPerfect™... -
Page 6: Package Contents
Package Contents Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice™ Customer Service for a replacement. 1x 29" Monitor • 1x DisplayPort® Cable •... -
Page 7: Product Overview
Product Overview Controls 1. CONTROL PAD Press the control pad to turn the display on/off. (Press for 5 sec for non-sleep) 2. LEFT Exit/RGB Ranges. (When the vertical screen is connected to the type-C device, long press the pop-up port to select the pop-up window) 3. - Page 8 Connections 6. AUDIO Insert the audio cable for the output of audio signals. 7. Type-C Insert one end of the Type-C cable into the computer’s Type-C output and connect the other end to the monitor’s Type-C port. 8. DP CONNECTORS Insert one end of the DP cable into the computer’s DP output and connect the other end to the monitor’s DP port.
-
Page 9: Installing The Stand
Installing The Stand Perform the following steps to assemble the stand and attach it to the monitor. Open the package, take out the product with the foam still attached, and gently place it on a desktop or table. 2. Take out the shaft assembly, bracket, and base. Use two (2) PM4x8 blue zinc-plated screws to lock the shaft assembly and bracket, and then use two (2) KM4x8 black zinc-plated screws to lock the bracket and base. - Page 10 3. Buckle the assembled bracket chassis on the whole machine (insert the upper part and press down). If you want to remove the bracket chassis, pull down the button on the rear shell to remove the bracket chassis. 4. Place the monitor on the desktop or table after completing the installation.
-
Page 11: Mount Installation
Mount Installation This device only includes screws that may be used when attaching the monitor to a VESA® 75x75mm type mount. No VESA mount or mounting accessories are included. Take out the whole machine (with Styrofoam) and place it on a horizontal table. -
Page 12: Indicator Light
4. The assembled device can be hung on the wall. Do not pinch the screen directly to prevent any damage. Indicator Light Solid blue light The power is on and the monitor is operating normally. Flashing blue light No video source, no horizontal or vertical signal has been detected, or the power is low. -
Page 13: Osd Menu Map
OSD Menu Map When the user flips the display, the function can also flip the OSD to achieve the best display angle. Main Sub-Menu Options Description Menu Input Type-C NONE Switch to Type-C Source signal input NONE Switch to DP signal input HDMI1 NONE... - Page 14 Gamma 2.0 Gamma 2.2 Gamma 2.4 Gamma 2.6 Picture Mode Standard, Photo, Set visual mode Movie, Game, according to activity Color FPS, RTS, sRGB Setting Color Warm, Cool, User Select color Temperature temperature Low Blue 0~100 Light 0~100 Adjust hue levels Saturation 0~100 Adjust saturation...
- Page 15 expression of gray scale MPRT On, Off Moving Picture Response Time Display Aspect Ratio Wide Screen, 4:3, Select on-screen 1:1, Auto aspect ratio Normal, Off, The lamp under the Flicker front frame and the lamp at the back are controlled LedMode synchronously Audio...
- Page 16 (When PBP phone is selected, the second window signal cannot be selected) PIP Size Small, Medium, Adjust the PIP and Large display window size PIP Position Top Right, Top Adjust the PIP Left, Bottom window position Right, Bottom Left Swap NONE Swap the two- channel signal...
- Page 17 OSD Time 5-100 Set how long the OSD remains open after non-use Normal,90,180,270 When the user flips Rotation the display, this function can also flip the OSD to achieve the best display angle (Cannot rotate in portrait mode) Other DP Version DP 1.4 Adaptive- Turn the Adaptive-...
-
Page 18: Troubleshooting
Troubleshooting Q1: The screen is blank. A1: Ensure that power is turned on. Check the contrast/brightness settings. If the LED INDICATOR is flashing, the monitor is not receiving a video signal. Check the display settings of the connected device. Q2: The image is out of focus. A2: Check the video cable connections. - Page 19 Q7: There is no video signal. A7: Confirm compatibility of the monitor and the graphics card. Inspect the condition of the ports on the monitor and graphics card. Q8: The image is dim. A8: Adjust the brightness and contrast. Q9: The image has jitter or a moire pattern A9: Ensure that nearby electronic equipment that may be causing interference are at a safe distance away from the device.
-
Page 20: Specifications
Specifications Model 42892 1x DisplayPort® 1.4, 3x HDMI® 2.0, Video Inputs 1x Type-C Display Size 27" Active Display Area 596.74x335.66m Panel Type IGZO Panel Model Sharp LQ270T1JG06 Maximum Resolution 2560x1440p Maximum Refresh Rate 180Hz VESA® Mount Size 75x75 Aspect Ration... - Page 21 Check the website for support times and links. To download the latest drivers, firmware, manuals, etc., go to www.monoprice.com and type 42892 into the search bar. If available, support files are linked at the bottom of the product page.
- Page 22 Regulatory compliance Notice for FCC This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 23 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Monoprice™, Dark Matter™, the Dark Matter logo, and all Monoprice logos are trademarks of Monoprice Inc. HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
- Page 24 www.monoprice.com Need Help? We’re here for you! Monoprice, Inc. Contact us: www.monoprice.com/contactus 1 Pointe Drive, Suite 400 Product pictures are for reference only. Brea, CA 92821 – USA Specifications described herein are subject to change without prior notification. Monoprice™ and all Monoprice logos are trademarks of Monoprice Inc. www.monoprice.com Copyright ©...
