SSB40 Wall Adapter Addendum
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS
Please read this entire manual before you begin.
If you have any questions, visit MantelMount.com or call
This Addendum is not a stand-alone set of instructions, it is only to be used
in conjunction with the MantelMount MM340 or MM540 Installation Manual.
The SSB40 Wall Adapter is a direct replacement for Item {32} Wall Frame.
MantelMount SSB40A Wall Adapter Addendum
ITEM NO.
PART NUMBER
1
15044
2
15055
12179
3
4
14126
SSB40A
5
TM
(800)-897-9755.
1
2
DESCRIPTION
SINGLE STUD UPPER BRACKET
SINGLE STUD LOWER BRACKET
ROUND SCREW M8 x 1.25 x 20mm
WASHER M8 x 2mm
INSTALLATION ADDENDUM
PAGE 1
Items 3 and 4 will
not be used in this
Addendum
3
4
QTY.
1
1
6
6
1
Advertisement
Related Manuals for MantelMount SSB40
Summary of Contents for MantelMount SSB40
- Page 1 This Addendum is not a stand-alone set of instructions, it is only to be used in conjunction with the MantelMount MM340 or MM540 Installation Manual. The SSB40 Wall Adapter is a direct replacement for Item {32} Wall Frame. Items 3 and 4 will...
- Page 2 When attaching the Adapter to a single stud, install three When attaching to a large vertical post or horizontal beam, Lag Bolts {17} included with MantelMount into the three you can choose to install four {17} Lag Bolts into the four vertical holes in the center of the Adapter.
