LED TV
ENGLISH
Easy Setup Guide
Please read this manual carefully before operating your set and retain it for future reference.
32LN662MBUB
ESPAÑOL
Guía Rápida de Configuración
Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.
FRANÇAIS
Guide de configuration rapide
Avant d'utiliser l'appareil, veuillez lire attentivement ce manuel et le conserver pour pouvoir vous y reporter ultérieurement.
Depending upon model / Según el modelo / Selon le modèle
www.lg.com
Printed in Korea / Imprimé en Corée
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG 32LN662MBUB
Summary of Contents for LG 32LN662MBUB
- Page 1 ENGLISH Easy Setup Guide Please read this manual carefully before operating your set and retain it for future reference. 32LN662MBUB ESPAÑOL Guía Rápida de Configuración Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.
- Page 2 ENGLISH Read Safety and Reference. WARNING : To prevent injury, this apparatus must be securely attached to the desk/wall in accordance with the Safety and Reference. ESPAÑOL Leer Seguridad y Consultas. ADVERTENCIA : Para prevenir daños, este aparato debe ser instalado a la mesa/pared de acuerdo a la guía de Seguridad y Consultas. FRANÇAIS Lisez Sécurité...
- Page 6 4.85 4,85 32LN662MBUB 55 W (29.0) (29,0) (17.3) (17,3) (3.3) (3,3) (10.6) (10,6) AC 120 V~ 50 / 60 Hz...
- Page 9 OWNER’S MANUAL Safety and Reference LED TV* * LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32LN662MBUB www.lg.com *MFL71988102* Copyright © 2023 LG Electronics Inc. All Rights Reserved.
-
Page 10: Table Of Contents
TABLE OF CONTENTS Settings Important Safety Instruction 16 Selecting Picture Mode Warning! Safety instructions 16 Adjusting the Brightness of a Picture 16 To use Energy Saving Feature Preparing Specifications Optional Extras 18 HDMI (PC) supported mode 18 HDMI (DTV) supported mode 8 Wall Mounting Bracket 18 Supported External Subtitles Lifting and Moving the TV... - Page 11 33 FCC Radio Frequency Interference Requirements (for UNII devices) 33 FCC RF Radiation Exposure Statement 34 Industry Canada Statement 34 IC Radiation Exposure Statement 34 RSS-247 Requirement 35 NOTE TO CABLE/TV INSTALLER 35 WARNING! (STABILITY HAZARD) 35 Symbols 35 LG Take-back & Recycling Policy...
-
Page 12: Important Safety Instruction
Important Safety Instruction • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. •... -
Page 13: Warning! Safety Instructions
Warning! Safety instructions - Do not expose to dripping or splashing and do not place objects filled with liquids, such as vases, cups, etc. on or over the apparatus (e.g., on shelves above the unit). - Near flammable objects such as gasoline CAUTION or candles, or expose the TV to direct air RISK OF ELECTRIC SHOCK... - Page 14 • Grounding (Except for devices which are not • Use only an authorized attachments / accessories grounded.) approved by LG Electronics. Otherwise, this may - TV with a three-prong grounded AC plug must be result in fire, electric shock, malfunction, or product connected to a three-prong grounded AC outlet.
-
Page 15: Preparing
Preparing • To reduce the risk of fire or electrical shock, do not touch the TV with wet hands. If the power cord prongs are wet or covered with dust, dry the power • When the TV is turned on for the first time after plug completely or wipe dust off. -
Page 16: Optional Extras
• Hold the top and bottom of the TV frame firmly. Make sure not to hold the transparent part, speaker, or speaker grille area. Model 32LN662MBUB VESA (A x B) 200 x 200 Standard screw Number of screws... -
Page 17: Using The Kensington Security System (Optional)
Using the Kensington Security • Use at least two people to move a large TV. • When transporting the TV by hand, hold the TV as System (optional) shown in the following illustration. (Depending upon model) The Kensington security system connector is located at the rear of the TV. -
Page 18: Securing Tv To The Wall
Detailed instructions will be included with the wall mount. We recommend that you use an LG brand wall mount. The LG wall mount is easy to adjust or to connect the cables. When you do not use LG’s wall mount bracket, use a wall mount bracket where the... -
Page 19: Connections
Connections • Remove the stand before installing the TV on a wall mount by performing the stand attachment in reverse. (Depending upon You can connect various external devices to the TV. model) For more information on external device’s connection, • For more information of screws and wall refer to the manual provided with each device. -
Page 20: Other Connections
Other connections Pillow Speaker Connect your TV to external devices. For the best Connect the pillow speaker (see example below) picture and audio quality, connect the external device to the PILLOW SPEAKER interface on the rear jack and the TV with the HDMI cable. panel of the TV. -
Page 21: Network Setup
Network setup External Devices Supported external devices are: Blu-ray player, HD (Depending upon model) receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other Wired network connection external devices. This TV can be connected to a Pro:Centric server •... -
Page 22: Using The Button
The software may be updated for improvement in button. performance. The customer is responsible to ensure the compatibility of their equipment with any LG Electronics software. If needed, please consult with LG Electronics and update new software versions according to the guidance provided by LG Electronics. - Page 23 • Abnormal Display • When cleaning the product, be careful not - If the TV feels cold to the touch, there may be a to allow any liquid or foreign objects to small flicker when it is turned on. This is normal; enter the gap between the upper, left or there is nothing wrong with TV.
-
Page 24: Settings
Settings Adjusting the Brightness of a Picture (All Settings) [Picture] [Advanced Settings] (Depending upon Model) [Brightness] * Remote control is not provided. Adjust the brightness of the entire screen. • [Panel Brightness] Controls the level of screen Selecting Picture Mode brightness by adjusting the backlight. -
Page 25: Specifications
Specifications Product specifications may be changed without prior notice due to upgrade of product functions. Estimated yearly energy consumption indicated on the FTC label is measured in accordance with the Test Procedures for Television Sets (USA only). The actual energy consumption depends on the usage environment (The content watched, TV settings, etc.). Broadcasting Specifications Television system ATSC, NTSC-M, 64 &... -
Page 26: Hdmi (Pc) Supported Mode
HDMI (PC) supported mode Supported External Subtitles Subtitle Format Horizontal Vertical Resolution Frequency (kHz) Frequency (Hz) *.smi, *.srt, *.sub (MicroDVD, 640 x 350 31.46 70.09 External SubViewer 1.0/2.0), *.ass, *.ssa, *.txt 720 x 400 31.46 70.08 Subtitle (TMPlayer), *.psb (PowerDivX), *.dcs 640 x 480 31.46 59.94... -
Page 27: Supported Audio Formats
Supported Audio Formats Supported Video Formats File Format Info Extension Codec (Bit rate) 32 Kbps - 320 Kbps VC-1 Advanced Profile Video (except for WMVA), VC-1 (Sample freq.) 16 kHz - 48 kHz .asf .mp3 Simple and Main Profiles (Support) MPEG1, MPEG2 .wmv WMA Standard (except for (channels) mono, stereo Audio WMA v1/ WMA Speech) -
Page 28: External Control Device Setup
External Control Device Phone jack Type Setup (Depending upon model) (PC) • You need to purchase the phone-jack to RS-232C cable required for the connection between the PC and the TV, which is specified in the manual. RS-232C Setup * For other models, connect to the USB port. •... -
Page 29: Rs-232C Configurations
RS-232C Configurations Communication Parameters • Baud rate: 9,600 bps (UART) 7-Wire Configurations • Data length: 8 bits (Standard RS-232C cable) • Parity: None • Stop bit: 1 bit • Communication code: ASCII code • Use a crossed (reverse) cable. Set ID For Set ID number, see “Real data mapping”. -
Page 30: Command Reference List
Command Reference List (Depending upon model) Data Command1 Command2 (Hexadecimal) 1 Power 00 to 01 2 Aspect Ratio (page 23) 3 Screen Mute (page 24) 4 Volume Mute 00 to 01 5 Volume Control 00 to 64 6 Contrast 00 to 64 7 Brightness 00 to 64 8 Color... -
Page 31: Transmission / Receiving Protocol
Transmission / Receiving Protocol 1 Power (Command: k a) ► To control Power On/Off of the set. (Depending upon Model) Transmission Transmission (k)(a)( )(Set ID)( )(Data)(Cr) (Command1)(Command2)( )(Set ID)( )(Data)(Cr) Data 00: Off Data 01: On (Command1): First command to control the TV. (j, k, m or x) (Command2): Second command to control the TV. - Page 32 3 Screen Mute (Command: k d) 6 Contrast (Command: k g) ► To select screen mute on/off. ► To adjust screen contrast. You can also adjust contrast in the picture settings. Transmission Transmission (k)(d)( )(Set ID)( )(Data)(Cr) (k)(g)( )(Set ID)( )(Data)(Cr) Data 00: Screen mute off (Picture on) / Video mute off Data Min: 00 to Max: 64 Data 01: Screen mute on (Picture off)
- Page 33 9 Tint (Command: k j) 12 Remote Control Lock Mode (Command: k m) ► To adjust the screen tint. ► To lock the front panel controls on the monitor and You can also adjust tint in the picture settings. remote control. Transmission Transmission (k)(m)( )(Set ID)( )(Data)(Cr)
- Page 34 15 Energy Saving (Command: j q) 17 Equalizer (Command: j v) ► To reduce the power consumption of the TV. You ► To adjust equalizer. can also adjust Energy Saving in picture settings. Transmission Transmission (j)(v)( )(Set ID)( )(Data)(Cr) (j)(q)( )(Set ID)( )(Data)(Cr) Power Saving Level Function...
- Page 35 18 Tune Command (Command: m a) 19 Channel Skip / Add (Command: m b) ► Select channel to following physical number. ► To set skip status for the current Channel. Transmission Transmission (m)(a)( )(Set ID)( )(Data 00)( )(Data 01)( )(Data 02)(Cr) (m)(b)( )(Set ID)( )(Data)(Cr) Data 00: High channel data Data 00: Skip...
- Page 36 22 Input select (Command: x b) (Main Picture 23 Channel block/unblock (Command: m d) Input) ► This command may work differently depending ► To select input source for main picture. upon model and signal. Transmission (For South Korea, North/Latin America except (x)(b)( )(Set ID)( )(Data)(Cr) Colombia Model) Data Structure...
- Page 37 24 Fail Over Mode (Command: m i) (For all other regions including Colombia, Excluding the above countries) ► Selects the Fail Over mode. Transmission Transmission (m)(d)( )(Set ID)( )(Data 00)( )(Data 01)( )(Data 02) (m)(i)( )(Set ID)( )(Data)(Cr) (Data 03)(Data 04)(Cr) Data 00: Off (Data 00): Physical Channel Number Data 01: Auto...
- Page 38 26 Internal storage media contents play * Real data mapping (Command: s n, a8) Step 0 ► Plays media stored in the internal memory. ► This command may work differently depending Step 10 (Set ID 10) upon model and signal. Transmission Step 15 (Set ID 15) (s)(n)( )(Set ID)( )(a)(8)( )(Data)(Cr)
-
Page 39: Ir Out Using Guide
If not use the remote-controller with data formats recommended, IR output signals will be suppressed automatically by IR receiver. In this case, LG does not guarantee IR working function. To make sure of this matter, here are two methods as below. -
Page 40: Open Source Software Notice Information
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by LG Electronics Inc. is under license. Other trademarks and trade names are those of their respective owners. -
Page 41: Regulatory
Regulatory FCC Radio Frequency Interference Requirements (for UNII devices) (For USA) FCC Notice High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. (For USA) These radar stations can cause interference with and/ This equipment has been tested and found to or damage this device. -
Page 42: Industry Canada Statement
Industry Canada Statement RSS-247 Requirement (For Canada) (For Canada) [For having wireless function (WLAN, Bluetooth,...)] [For product having the wireless function using 5 GHz frequency bands] This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and (1) The device for operation in the band 5150–5250 Economic Development Canada’s licence-exempt MHz is only for indoor use to reduce the potential for RSS(s). -
Page 43: Note To Cable/Tv Installer
Refers to dangerous voltage. WARNING! (STABILITY HAZARD) LG Take-back & Recycling Policy A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: –... - Page 47 CHILD SAFETY: PROPER TELEVISION PLACEMENT MATTERS THE CONSUMER TECHNOLOGY INDUSTRY CARES Manufacturers, retailers and the rest of the consumer technology industry are committed to making products safe and enjoyable. As you enjoy your television, please note that all televisions – new and old- must be supported on proper stands or installed according to the manufacturer’s recommendations.
- Page 48 Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632 E-mail lg.environmental@lge.com LG Customer Information Center The model and serial number of the product are located on the back and on one side of the product.
