INSTALLATION GUIDE
Step 6
Assembly
Mount and screw the assembly into the dash cavity, then reassemble
everything in reverse order to complete the installation.
Kit Assembly
TA2122B 02/16
4
IN-DASH INSTALLATION KIT FOR
2016-UP TOYOTA TACOMA VEHICLES EQUIPPED W/
BASE STEREO
7746 Right Bracket
TA2122B
Face Panel
PRT (Panel Removal Tool)
Screwdriver
This premium installation kit is for 2016-UP Toyota Tacoma vehicles with base model radio. Included are all the parts
you need to mount your car stereo or CD player into your vehicle's dash. Refer to individual instruction in this manual to
remove your vehicles factory radio and assemble the kit.
TA2122B
7745 Right Bracket
6552 Pocket
TA2122B 02/16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Scosche TA2122B
Summary of Contents for Scosche TA2122B
- Page 1 This premium installation kit is for 2016-UP Toyota Tacoma vehicles with base model radio. Included are all the parts you need to mount your car stereo or CD player into your vehicle’s dash. Refer to individual instruction in this manual to remove your vehicles factory radio and assemble the kit. TA2122B 02/16 TA2122B 02/16...
- Page 2 Using a PRT (Panel Removal SINGLE DIN RADIO Tool) remove the air vent duct Attach provided 6552 (pocket) to the back side of the TA2122B face panel using the screws provided. panel surrounding the OEM Attach the 7745 &7746 (brackets) to the pocket face panel assembly.
