- Page 1 DA 174 Winch Motor Technical User Guide For other language variants of this document we refer to http://docs.skov.com/1080 your local dealer. 2016.06.08 • 603943...
- Page 3 Should any mistakes or imprecise information occur in spite of this, SKOV A/S would appreciate being notified thereof. • Irrespective of the above, SKOV A/S shall not accept any liability with regard to loss or damage caused or alleged to be caused by reliance on any information contained herein.
-
Page 4: Table Of Contents
Interlinking ....................... 7 DA 1500 ceiling inlet - DA 174/380 mm stepless ............... 7 DA 1211B wall inlet in ceiling as Combi-Diffuse inlet – DA 174/380 mm ......7 DA 1200 wall inlet – DA 174/380 mm stepless ..............7 Windows –... -
Page 5: Product Description
Technical User Guide 1 Product Description DA 174 is a linear 24 V winch motor for regulation of wall and ceiling inlets in livestock house ventilation systems. The typical application is in houses, where it is possible to connect several units to the same winch motor via a mechanical connection in the form of a pull rod or wire. -
Page 6: Mounting Guide
Centre distance from wall 40mm This installation is e.g. used for operation of 40 mm built-in inlets. Centre distance from wall 80mm At operation of flange inlets, more distance is 80 mm required. DA 174 Winch Motor... -
Page 7: Straight Pull
The inlet must be completely closed when inlets/windows, which open at slack, are connected to pull rod or wire. Inlets and flaps, which open at pull, must be completely open when they are connected to pull rod or wire. DA 1500 ceiling inlet - DA 174/380 mm stepless 38 cm Opens at pull. -
Page 8: Windows - Da 174/380 Mm
Ensure space for max. length of stroke of 380 mm. C.f. 3.8 mechanical reduction, if necessary. Shutter in outlet – DA 174/380 mm stepless Opens at pull. The piston of the winch motor must be pressed home and the 38cm shutters completely open when they are connected. -
Page 9: Mechanical Reduction Of The Pulling / Slacking Length
A corresponding solution with the application of a stop unit mounted directly on wire in connection with the application of pulleys. 4 Cleaning Clean the product with water and a brush without using: high-pressure cleaner solvents corrosive/caustic agents DA 174 Winch Motor... -
Page 10: Installation Guide
DA 174 stepless NB Please note colour code of the 5-core cable The winch motor DA 174 is mounted with a 5-core cable, which is mounted in the terminals R1 and J6 of the climate computer. The terminals Y1-8 of the control box must be connected to the terminals of the computer by means of a 7-core cable according to the set-up of the computer (Show installation). -
Page 11: Stepless Type - Opens At Slack
DA 174 stepless NB Please note colour code of the 5-core cable The winch motor DA 174 is mounted with a 5-core cable, which is mounted in the terminals R1 and J6 of the climate computer. The terminals Y1-8 of the control box must be connected to the terminals of the computer by means of a 7-core cable according to the set-up of the computer (Show installation). -
Page 12: On/Off Type - Opens At Slack
DA 174 ON/OFF The winch motor DA 174 is mounted with a 2-core cable, which must be mounted in terminal J6 of the control box. The terminals Y1-5 of the control box must be connected to the terminals of the computer by means of a 5-core cable according to the set-up of the computer (Show installation). -
Page 13: Technical Data
Technical User Guide 6 Technical Data Winch motor DA 174 24V 380 mm stepless Operating voltage 24V DC ± 15% Power consumption 1.6 A Intermittence Max. tensile force 100 kg -10 – 55 °C Temperature, operation Running time between limit switches 108 sec. - Page 14 2006/42/EC (Directive on Machinery) Standards: EN 61000-6-2:2005 + AC:2005 EN 61000-6-4:2007 + A1:2011 We declare as manufacturer that the products meet the requirements of the listed directives and standards. Location: Hedelund 4, DK-7870 Roslev Date: 2016.06.08 Jesper Mogensen DA 174 Winch Motor...
- Page 16 SKOV A/S • Hedelund 4 • Glyngøre • DK-7870 Roslev Tel. +45 72 17 55 55 • Fax +45 72 17 59 59 • www.skov.com • E-mail: skov@skov.dk...
